8K53 | pdb_00008k53

Structure of the Dimeric Human CNTN2 Ig 1-6-FNIII 1-2 Domain in an Asymmetric State

PDB DOI: https://doi.org/10.2210/pdb8K53/pdb
EM Map EMD-36896: EMDB EMDataResource

Classification: CELL ADHESION
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2023-07-21 Released: 2023-12-06
Deposition Author(s): Zhang, Z.Z.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.80 Å
Aggregation State: CELL
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8K53

This is version 1.2 of the entry. See complete history.

Literature

Structure of human CNTN2 immunoglobulin domains 1-6 homo-dimer

Zhang, Z.Z., Shi, Z.B., Wang, D.P.

To be published.

Macromolecule Content

Total Structure Weight: 217.69 kDa
Atom Count: 10,602
Modeled Residue Count: 1,350
Deposited Residue Count: 1,964
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Contactin-2	A, B	982	Homo sapiens	Mutation(s): 0 Gene Names: CNTN2, AXT, TAG1, TAX1
UniProt & NIH Common Fund Data Resources
Find proteins for Q02246 (Homo sapiens) Explore Q02246 Go to UniProtKB: Q02246
PHAROS: Q02246 GTEx: ENSG00000184144
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q02246
Glycosylation
Glycosylation Sites: 3	Glycosylation Focus chain A Focus chain B	Go to GlyGen: Q02246-1
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C	3		N-Glycosylation	Interactions Focus chain C Interactions & Density Focus chain C
Glycosylation Resources
GlyTouCan: G15407YE GlyCosmos: G15407YE GlyGen: G15407YE

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	D, E, F	2		N-Glycosylation	Interactions Focus chain D Focus chain E Focus chain F Interactions & Density Focus chain D Focus chain E Focus chain F
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download:Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain H [auth A] SDF format, chain G [auth A] MOL2 format, chain I [auth B] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] mmCIF format, chain I [auth B] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A]	G [auth A], H [auth A], I [auth B]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.80 Å
Aggregation State: CELL
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-12-06

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	82201315
National Natural Science Foundation of China (NSFC)	China	K19381005

Revision History (Full details and data files)

Version 1.0: 2023-12-06
Type: Initial release
Version 1.1: 2024-10-16
Changes: Data collection, Structure summary
Version 1.2: 2025-06-25
Changes: Data collection
