8K24 | pdb_00008k24

ICP1 Csy-dsDNA-Cas1-Cas2/3 complex (fully assembled form), C2 symmetry

• PDB DOI: https://doi.org/10.2210/pdb8K24/pdb
• EM Map EMD-36827: EMDB EMDataResource
• NAKB: 8K24

• Classification: RNA BINDING PROTEIN/DNA/RNA
• Organism(s): Vibrio phage ICP1_2004_A
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2023-07-12 Released: 2024-07-17
• Deposition Author(s): Zhang, L.X., Feng, Y.
• Funding Organization(s): National Science Foundation (NSF, China)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.72 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Structure of csy complex with long DNA State2

Zhang, L.X., Feng, Y.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Hetero 24-mer - A12B4C2D2E2F2

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 984.08 kDa
• Atom Count: 67,211
• Modeled Residue Count: 8,150
• Deposited Residue Count: 8,262
• Unique protein chains: 6
• Unique nucleic acid chains: 4

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
HD Cas3-type domain-containing protein	A [auth a], DA [auth A]	930	Vibrio phage ICP1_2004_A	Mutation(s): 0  Gene Names: TUST1-10_00455

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Csy1	B [auth b], P [auth B]	179	Vibrio phage ICP1_2004_A	Mutation(s): 0  Gene Names: TUST1-10_00450

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Csy2	C [auth c], Q [auth C]	248	Vibrio phage ICP1_2004_A	Mutation(s): 0  Gene Names: TUST1-10_00445

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Cas1	D [auth d], E [auth e], R [auth D], S [auth E]	302	Vibrio phage ICP1_2004_A	Mutation(s): 0  Gene Names: TUST1-10_00460

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
Csy3	F [auth g], H [auth i], I [auth j], J [auth k], K [auth l], L [auth m], T [auth G], V [auth I], W [auth J], X [auth K], Y [auth L], Z [auth M]	306	Vibrio phage ICP1_2004_A	Mutation(s): 0  Gene Names: TUST1-10_00440

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
Csy4	G [auth h], U [auth H]	168	Vibrio phage ICP1_2004_A	Mutation(s): 0  Gene Names: TUST1-10_00435

Entity ID: 7
Molecule	Chains	Length	Organism	Image
RNA (60-MER)	AA [auth P], M [auth p]	60	Vibrio phage ICP1_2004_A

Entity ID: 8
Molecule	Chains	Length	Organism	Image
DNA (43-MER)	BA [auth Q], EA [auth U], N [auth q]	43	Vibrio phage ICP1_2004_A

Entity ID: 9
Molecule	Chains	Length	Organism	Image
DNA (31-MER)	CA [auth R], O [auth r]	31	Vibrio phage ICP1_2004_A

Entity ID: 10
Molecule	Chains	Length	Organism	Image
DNA (5'-D(*AP*TP*CP*TP*TP*CP*CP*CP*TP*AP*TP*TP*TP*AP*AP*AP*TP*TP*GP*CP*T)-3')	FA [auth V]	21	Vibrio phage ICP1_2004_A

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MN (Subject of Investigation/LOI)	GA [auth a], HA [auth a], IA [auth A], JA [auth A]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.72 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2024-07-17
Deposition Author(s): Zhang, L.X., Feng, Y.

---

Funding Organization	Location	Grant Number
National Science Foundation (NSF, China)	China	32171274

Revision History

• Version 1.0: 2024-07-17
  Type: Initial release
