8JFW | pdb_00008jfw

Cryo-EM structure of RDGC/apo-CaM complex

PDB DOI: https://doi.org/10.2210/pdb8JFW/pdb
EM Map EMD-36218: EMDB EMDataResource

Classification: HYDROLASE
Organism(s): Drosophila melanogaster
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2023-05-19 Released: 2024-11-27
Deposition Author(s): Liu, Z.M., Liu, W., Wu, C., Liu, J.
Funding Organization(s): National Science Foundation (NSF, China)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.64 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8JFW

This is version 1.1 of the entry. See complete history.

Literature

Cryo-EM structure of RDGC/apo-CaM complex

Liu, Z.M., Liu, W., Wu, C., Liu, J.

To be published.

Macromolecule Content

Total Structure Weight: 92.57 kDa
Atom Count: 6,076
Modeled Residue Count: 758
Deposited Residue Count: 810
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
AT15141p	A	149	Drosophila melanogaster	Mutation(s): 0 Gene Names: Cam-RB
UniProt
Find proteins for C6SUZ2 (Drosophila melanogaster) Explore C6SUZ2 Go to UniProtKB: C6SUZ2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	C6SUZ2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Serine/threonine-protein phosphatase rdgC	B [auth D]	661	Drosophila melanogaster	Mutation(s): 0 Gene Names: rdgC, CG44746 EC: 3.1.3.16
UniProt
Find proteins for P40421 (Drosophila melanogaster) Explore P40421 Go to UniProtKB: P40421
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P40421
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN (Subject of Investigation/LOI) Query on ZN Download:Ideal Coordinates CCD File SDF format, chain D MOL2 format, chain D mmCIF format, chain D	D	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain D Interactions & Density Focus chain D
FE (Subject of Investigation/LOI) Query on FE Download:Ideal Coordinates CCD File SDF format, chain C [auth D] MOL2 format, chain C [auth D] mmCIF format, chain C [auth D]	C [auth D]	FE (III) ION Fe VTLYFUHAOXGGBS-UHFFFAOYSA-N		Interactions Focus chain C [auth D] Interactions & Density Focus chain C [auth D]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.64 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-11-27

Deposition Author(s):

Funding Organization	Location	Grant Number
National Science Foundation (NSF, China)	China	--

Revision History (Full details and data files)

Version 1.0: 2024-11-27
Type: Initial release
Version 1.1: 2025-07-02
Changes: Data collection
