8J1G | pdb_00008j1g

Structure of amino acid dehydrogenase in complex with NADPH


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:
    0.274 (Depositor), 0.274 (DCC)
  • R-Value Work:
    0.225 (Depositor), 0.235 (DCC)
  • R-Value Observed:
    0.228 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 8J1G

Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history

Literature

First crystal structure of an NADP + -dependent l-arginine dehydrogenase belonging to the mu-crystallin family.

Kawakami, R.Takami, N.Hayashi, J.Yoneda, K.Ohmori, T.Ohshima, T.Sakuraba, H.

(2023) Int J Biol Macromol 249: 126070-126070

  • DOI: https://doi.org/10.1016/j.ijbiomac.2023.126070
  • Primary Citation Related Structures:
    8J1C, 8J1G

  • PubMed Abstract:

    Crystal structures of Pseudomonas veroniil-arginine dehydrogenase (l-ArgDH), belonging to the μ-crystallin/ornithine cyclodeaminase family, were determined for the enzyme in complex with l-lysine and NADP + and with l-arginine and NADPH. The main chain coordinates of the P. veroniil-ArgDH monomer showed notable similarity to those of Archaeoglobus fulgidusl-AlaDH, belonging to the same family, and pro-R specificity similar to l-AlaDH for hydride transfer to NADP + was postulated. However, the residues recognizing the α-amino group of the substrates differed between the two enzymes. Based on a substrate modeling study, it was proposed that in A. fulgidusl-AlaDH, the amino group of l-alanine interacts via a water molecule (W510) with the side chains of Lys41 and Arg52. By contrast, the α-amino group of l-arginine formed hydrogen bonds with the side chains of Thr224 and Asn225 in P. veroniil-ArgDH. Moreover, the guanidino group of l-arginine was fixed into the active site via hydrogen bonds with the side chain of Asp54. Site-directed mutagenesis suggested that Asp54 plays an important role in maintaining high reactivity against the substrate and that Tyr58 and Lys71 play critical roles in enzyme catalysis.


  • Organizational Affiliation
    • Division of Bioscience and Bioindustry, Graduate School of Technology, Industrial and Social Sciences, Tokushima University, 2-1, Minamijosanjima-cho, Tokushima 770-8513, Tokushima, Japan.

Macromolecule Content

  • Total Structure Weight: 147.95 kDa
  • Atom Count: 9,489
  • Modeled Residue Count: 1,219
  • Deposited Residue Count: 1,344
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ornithine cyclodeaminase family protein
A, B, C, D
336Pseudomonas veroniiMutation(s): 0
Gene Names: HBO43_18005
UniProt
Find proteins for A0A7Y0ZV07 (Pseudomonas veronii)
Explore A0A7Y0ZV07
Go to UniProtKB:  A0A7Y0ZV07
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A7Y0ZV07
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NDP
(Subject of Investigation/LOI)

Query on NDP



Download:Ideal Coordinates CCD File
E [auth A],
H [auth B],
K [auth C],
M [auth D]
NADPH DIHYDRO-NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H30 N7 O17 P3
ACFIXJIJDZMPPO-NNYOXOHSSA-N
ARG

Query on ARG



Download:Ideal Coordinates CCD File
F [auth A],
I [auth B],
L [auth C],
N [auth D]
ARGININE
C6 H15 N4 O2
ODKSFYDXXFIFQN-BYPYZUCNSA-O
EDO
(Subject of Investigation/LOI)

Query on EDO



Download:Ideal Coordinates CCD File
G [auth A],
J [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:  0.274 (Depositor), 0.274 (DCC)
  • R-Value Work:  0.225 (Depositor), 0.235 (DCC)
  • R-Value Observed: 0.228 (Depositor)
Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 63.473α = 88.65
b = 70.306β = 72.53
c = 100.137γ = 86.53
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
XDSdata reduction
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of Science (JSPS)Japan23K05658

Revision History  (Full details and data files)

  • Version 1.0: 2023-08-16
    Type: Initial release
