8IN7 | pdb_00008in7

Crystal structure of UGT74AN3-UDP

PDB DOI: https://doi.org/10.2210/pdb8IN7/pdb

Classification: TRANSFERASE
Organism(s): Catharanthus roseus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-03-08 Released: 2024-03-13
Deposition Author(s): Feng, L., Wei, H.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.223 (Depositor), 0.224 (DCC)
R-Value Work:
0.184 (Depositor), 0.186 (DCC)
R-Value Observed:
0.186 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8IN7

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of UGT74AN3-UDP

Wei, H., Wei, H.

To be published.

Macromolecule Content

Total Structure Weight: 54.14 kDa
Atom Count: 3,743
Modeled Residue Count: 432
Deposited Residue Count: 474
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycosyltransferase	A	474	Catharanthus roseus	Mutation(s): 0 EC: 2.4.1
UniProt
Find proteins for W8JMV4 (Catharanthus roseus) Explore W8JMV4 Go to UniProtKB: W8JMV4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	W8JMV4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
UPG (Subject of Investigation/LOI) Query on UPG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	URIDINE-5'-DIPHOSPHATE-GLUCOSE C₁₅ H₂₄ N₂ O₁₇ P₂ HSCJRCZFDFQWRP-JZMIEXBBSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.223 (Depositor), 0.224 (DCC)
R-Value Work: 0.184 (Depositor), 0.186 (DCC)
R-Value Observed: 0.186 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.437	α = 90
b = 52.068	β = 90
c = 200.195	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Blu-Ice	data collection
XDS	data reduction
Aimless	data scaling
PHENIX	model building
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-03-13

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2024-03-13
Type: Initial release
