8HCT

Crystal structure of Cu2+ binding to Dendrorhynchus zhejiangensis ferritin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.26 Å
  • R-Value Free: 0.226
  • R-Value Work: 0.164
  • R-Value Observed: 0.167

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Structural and Biochemical Characterization of Silver/Copper Binding by Dendrorhynchus zhejiangensis Ferritin.

Huo, C.Ming, T.Wu, Y.Huan, H.Qiu, X.Lu, C.Li, Y.Zhang, Z.Han, J.Su, X.

(2023) Polymers (Basel) 15

  • DOI: https://doi.org/10.3390/polym15051297
  • Primary Citation of Related Structures:
    8GY1, 8HCT

  • PubMed Abstract:

    Ferritin with a highly symmetrical cage-like structure is not only key in the reversible storage of iron in efficient ferroxidase activity; it also provides unique coordination environments for the conjugation of heavy metal ions other than those associated with iron. However, research regarding the effect of these bound heavy metal ions on ferritin is scarce. In the present study, we prepared a marine invertebrate ferritin from Dendrorhynchus zhejiangensis (DzFer) and found that it could withstand extreme pH fluctuation. We then demonstrated its capacity to interact with Ag + or Cu 2+ ions using various biochemical and spectroscopic methods and X-ray crystallography. Structural and biochemical analyses revealed that both Ag + and Cu 2+ were able to bind to the DzFer cage via metal-coordination bonds and that their binding sites were mainly located inside the three-fold channel of DzFer. Furthermore, Ag + was shown to have a higher selectivity for sulfur-containing amino acid residues and appeared to bind preferentially at the ferroxidase site of DzFer as compared with Cu 2+ . Thus, it is far more likely to inhibit the ferroxidase activity of DzFer. The results provide new insights into the effect of heavy metal ions on the iron-binding capacity of a marine invertebrate ferritin.


  • Organizational Affiliation

    State Key Laboratory for Managing Biotic and Chemical Threats to the Quality and Safety of Agro-Products, Ningbo University, Ningbo 315211, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ferritin169DendrorhynchusMutation(s): 0
EC: 1.16.3.1
UniProt
Find proteins for A0A8F4Y4C2 (Lineidae sp. TWL-2008)
Explore A0A8F4Y4C2
Go to UniProtKB:  A0A8F4Y4C2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A8F4Y4C2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GOL (Subject of Investigation/LOI)
Query on GOL

Download Ideal Coordinates CCD File
I [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CU (Subject of Investigation/LOI)
Query on CU

Download Ideal Coordinates CCD File
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A]
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
FE (Subject of Investigation/LOI)
Query on FE

Download Ideal Coordinates CCD File
B [auth A],
C [auth A]
FE (III) ION
Fe
VTLYFUHAOXGGBS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.26 Å
  • R-Value Free: 0.226
  • R-Value Work: 0.164
  • R-Value Observed: 0.167
  • Space Group: I 4 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 151.011α = 90
b = 151.011β = 90
c = 151.011γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-3000data reduction
HKL-3000data scaling
BALBESphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China41676159

Revision History  (Full details and data files)

  • Version 1.0: 2023-03-29
    Type: Initial release
  • Version 1.1: 2024-05-29
    Changes: Data collection
