8GAF | pdb_00008gaf

Exploiting Activation and Inactivation Mechanisms in Type I-C CRISPR-Cas3 for Genome Editing Applications


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.64 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8GAF

This is version 1.0 of the entry. See complete history

Literature

Exploiting activation and inactivation mechanisms in type I-C CRISPR-Cas3 for genome-editing applications.

Hu, C.Myers, M.T.Zhou, X.Hou, Z.Lozen, M.L.Nam, K.H.Zhang, Y.Ke, A.

(2024) Mol Cell 84: 463-475.e5

  • DOI: https://doi.org/10.1016/j.molcel.2023.12.034
  • Primary Citation Related Structures:
    8G9S, 8G9T, 8G9U, 8GAF, 8GAM, 8GAN

  • PubMed Abstract:

    Type I CRISPR-Cas systems utilize the RNA-guided Cascade complex to identify matching DNA targets and the nuclease-helicase Cas3 to degrade them. Among the seven subtypes, type I-C is compact in size and highly active in creating large-sized genome deletions in human cells. Here, we use four cryoelectron microscopy snapshots to define its RNA-guided DNA binding and cleavage mechanisms in high resolution. The non-target DNA strand (NTS) is accommodated by I-C Cascade in a continuous binding groove along the juxtaposed Cas11 subunits. Binding of Cas3 further traps a flexible bulge in NTS, enabling NTS nicking. We identified two anti-CRISPR proteins AcrIC8 and AcrIC9 that strongly inhibit Neisseria lactamica I-C function. Structural analysis showed that AcrIC8 inhibits PAM recognition through allosteric inhibition, whereas AcrIC9 achieves so through direct competition. Both Acrs potently inhibit I-C-mediated genome editing and transcriptional modulation in human cells, providing the first off-switches for type I CRISPR eukaryotic genome engineering.


  • Organizational Affiliation
    • Department of Molecular Biology and Genetics, Cornell University, 253 Biotechnology Building, Ithaca, NY 14853, USA; Department of Biological Sciences, Faculty of Science; Department of Biochemistry, Precision Medicine Translational Research Programme (TRP), Yong Loo Lin School of Medicine, National University of Singapore, Singapore 117597, Singapore.

Macromolecule Content

  • Total Structure Weight: 421.07 kDa
  • Atom Count: 24,582
  • Modeled Residue Count: 3,004
  • Deposited Residue Count: 3,641
  • Unique protein chains: 4
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Cas7
A,
B,
C,
D,
E,
F,
L [auth M]
283Neisseria lactamicaMutation(s): 0
Gene Names: NCTC10618_01084
UniProt
Find proteins for D0W8X6 (Neisseria lactamica ATCC 23970)
Explore D0W8X6
Go to UniProtKB:  D0W8X6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD0W8X6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Cas8
G, H
582Neisseria lactamicaMutation(s): 0
Gene Names: B2G52_10005
UniProt
Find proteins for D0W8X5 (Neisseria lactamica ATCC 23970)
Explore D0W8X5
Go to UniProtKB:  D0W8X5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD0W8X5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Cas11
I, J
124Neisseria lactamicaMutation(s): 0
Gene Names: NCTC10618_01085
UniProt
Find proteins for D0W8X5 (Neisseria lactamica ATCC 23970)
Explore D0W8X5
Go to UniProtKB:  D0W8X5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD0W8X5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
Cas5M [auth N]205Neisseria lactamicaMutation(s): 0
Gene Names: cas5d
EC: 3.1
UniProt
Find proteins for D0W8X4 (Neisseria lactamica ATCC 23970)
Explore D0W8X4
Go to UniProtKB:  D0W8X4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD0W8X4
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 4
MoleculeChains LengthOrganismImage
crRNA (43-MER)43Neisseria lactamica
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.64 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Center for Research Resources (NIH/NCRR)United StatesGM118174

Revision History  (Full details and data files)

  • Version 1.0: 2024-03-06
    Type: Initial release
