8FTK | pdb_00008ftk

Chaetomium thermophilum SETX (Full-length)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.56 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8FTK

This is version 1.2 of the entry. See complete history

Literature

Sen1 architecture: RNA-DNA hybrid resolution, autoregulation, and insights into SETX inactivation in AOA2.

Appel, C.D.Bermek, O.Dandey, V.P.Wood, M.Viverette, E.Williams, J.G.Bouvette, J.Riccio, A.A.Krahn, J.M.Borgnia, M.J.Williams, R.S.

(2023) Mol Cell 83: 3692

  • DOI: https://doi.org/10.1016/j.molcel.2023.09.024
  • Primary Citation Related Structures:
    8FTH, 8FTK, 8FTM

  • PubMed Abstract:

    The senataxin (SETX, Sen1 in yeasts) RNA-DNA hybrid resolving helicase regulates multiple nuclear transactions, including DNA replication, transcription, and DNA repair, but the molecular basis for Sen1 activities is ill defined. Here, Sen1 cryoelectron microscopy (cryo-EM) reconstructions reveal an elongated inchworm-like architecture. Sen1 is composed of an amino terminal helical repeat Sen1 N-terminal (Sen1N) regulatory domain that is flexibly linked to its C-terminal SF1B helicase motor core (Sen1 Hel ) via an intrinsically disordered tether. In an autoinhibited state, the Sen1 Sen1N domain regulates substrate engagement by promoting occlusion of the RNA substrate-binding cleft. The X-ray structure of an activated Sen1 Hel engaging single-stranded RNA and ADP-SO 4 shows that the enzyme encircles RNA and implicates a single-nucleotide power stroke in the Sen1 RNA translocation mechanism. Together, our data unveil dynamic protein-protein and protein-RNA interfaces underpinning helicase regulation and inactivation of human SETX activity by RNA-binding-deficient mutants in ataxia with oculomotor apraxia 2 neurodegenerative disease.


  • Organizational Affiliation
    • Genome Integrity and Structural Biology Laboratory, National Institute of Environmental Health Sciences, National Institutes of Health, Department of Health and Human Services, Research Triangle Park, NC 27709, USA.

Macromolecule Content

  • Total Structure Weight: 223.79 kDa
  • Atom Count: 7,840
  • Modeled Residue Count: 1,584
  • Deposited Residue Count: 1,993
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
5'-3' RNA helicase-like protein1,993Thermochaetoides thermophila DSM 1495Mutation(s): 0
Gene Names: CTHT_0012480
EC: 3.6.4.12
UniProt
Find proteins for G0S163 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0S163
Go to UniProtKB:  G0S163
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0S163
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.56 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United States1ES102765

Revision History  (Full details and data files)

  • Version 1.0: 2023-10-25
    Type: Initial release
  • Version 1.1: 2023-11-01
    Changes: Database references
  • Version 1.2: 2025-05-28
    Changes: Data collection, Structure summary
