8FCV | pdb_00008fcv

Cryo-EM structure of TnsC-TniQ-DNA complex in type I-B CAST system


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.95 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8FCV

This is version 1.3 of the entry. See complete history

Literature

Molecular mechanism for Tn7-like transposon recruitment by a type I-B CRISPR effector.

Wang, S.Gabel, C.Siddique, R.Klose, T.Chang, L.

(2023) Cell 186: 4204-4215.e19

  • DOI: https://doi.org/10.1016/j.cell.2023.07.010
  • Primary Citation Related Structures:
    8FCJ, 8FCU, 8FCV, 8FCW, 8FCX, 8FD2, 8FD3, 8FF4, 8FF5

  • PubMed Abstract:

    Tn7-like transposons have co-opted CRISPR-Cas systems to facilitate the movement of their own DNA. These CRISPR-associated transposons (CASTs) are promising tools for programmable gene knockin. A key feature of CASTs is their ability to recruit Tn7-like transposons to nuclease-deficient CRISPR effectors. However, how Tn7-like transposons are recruited by diverse CRISPR effectors remains poorly understood. Here, we present the cryo-EM structure of a recruitment complex comprising the Cascade complex, TniQ, TnsC, and the target DNA in the type I-B CAST from Peltigera membranacea cyanobiont 210A. Target DNA recognition by Cascade induces conformational changes in Cas6 and primes TniQ recruitment through its C-terminal domain. The N-terminal domain of TniQ is bound to the seam region of the TnsC spiral heptamer. Our findings provide insights into the diverse mechanisms for the recruitment of Tn7-like transposons to CRISPR effectors and will aid in the development of CASTs as gene knockin tools.


  • Organizational Affiliation
    • Department of Biological Sciences, Purdue University, West Lafayette, IN 47907, USA.

Macromolecule Content

  • Total Structure Weight: 382.95 kDa
  • Atom Count: 23,116
  • Modeled Residue Count: 2,755
  • Deposited Residue Count: 3,130
  • Unique protein chains: 2
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
TniQC [auth P]329Nostoc sp. 'Peltigera membranacea cyanobiont' 210AMutation(s): 0
Gene Names: CDG76_09005
UniProt
Find proteins for A0ACD6BA42 (Nostoc sp. 'Peltigera membranacea cyanobiont' 210A)
Explore A0ACD6BA42
Go to UniProtKB:  A0ACD6BA42
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6BA42
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
TnsC383Nostoc sp. 'Peltigera membranacea cyanobiont' 210AMutation(s): 0
Gene Names: CDG76_08990
UniProt
Find proteins for A0ACD6BA40 (Nostoc sp. 'Peltigera membranacea cyanobiont' 210A)
Explore A0ACD6BA40
Go to UniProtKB:  A0ACD6BA40
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6BA40
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (60-MER)A [auth N]60synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (60-MER)B [auth O]60synthetic construct
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP

Query on ATP



Download:Ideal Coordinates CCD File
K [auth Q]
M [auth R]
O [auth S]
Q [auth T]
S [auth U]
K [auth Q],
M [auth R],
O [auth S],
Q [auth T],
S [auth U],
U [auth V],
W
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
L [auth Q]
N [auth R]
P [auth S]
R [auth T]
T [auth U]
L [auth Q],
N [auth R],
P [auth S],
R [auth T],
T [auth U],
V,
X [auth W]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.95 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2023-08-09
    Type: Initial release
  • Version 1.1: 2023-08-23
    Changes: Data collection, Database references
  • Version 1.2: 2023-09-27
    Changes: Database references
  • Version 1.3: 2024-01-31
    Changes: Source and taxonomy
