8EAO | pdb_00008eao

Cryo-EM structure of the in-situ gp1-gp4 complex from bacteriophage P22

PDB DOI: https://doi.org/10.2210/pdb8EAO/pdb
EM Map EMD-27792: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Salmonella phage P22
Mutation(s): No

Deposited: 2022-08-29 Released: 2023-09-06
Deposition Author(s): Wang, C., Liu, J., Molineux, I.J.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.20 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8EAO

This is version 1.1 of the entry. See complete history.

Literature

In-situ structure of tail machine reveals mechanistic insights into P22 assembly.

Wang, C., Liu, J., Molineux, I.J.

To be published.

Macromolecule Content

Total Structure Weight: 1,048.17 kDa
Atom Count: 71,628
Modeled Residue Count: 8,964
Deposited Residue Count: 9,240
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptidoglycan hydrolase gp4	A, C, E, G, I A, C, E, G, I, K, M, O, Q, S, U, W	149	Salmonella phage P22	Mutation(s): 0
UniProt
Find proteins for P26746 (Salmonella phage P22) Explore P26746 Go to UniProtKB: P26746
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P26746
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Portal protein	B, D, F, H, J B, D, F, H, J, L, N, P, R, T, V, X	621	Salmonella phage P22	Mutation(s): 0
UniProt
Find proteins for P26744 (Salmonella phage P22) Explore P26744 Go to UniProtKB: P26744
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P26744
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.20 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-09-06

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	--

Revision History (Full details and data files)

Version 1.0: 2023-09-06
Type: Initial release
Version 1.1: 2025-06-04
Changes: Data collection, Structure summary
