8E9A | pdb_00008e9a

Crystal structure of AsfvPolX in complex with 10-23 DNAzyme and Mg


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free:
    0.289 (Depositor), 0.289 (DCC)
  • R-Value Work:
    0.255 (Depositor), 0.256 (DCC)
  • R-Value Observed:
    0.257 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8E9A

This is version 1.3 of the entry. See complete history

Literature

Structure of a 10-23 deoxyribozyme exhibiting a homodimer conformation.

Cramer, E.R.Starcovic, S.A.Avey, R.M.Kaya, A.I.Robart, A.R.

(2023) Commun Chem 6: 119-119

  • DOI: https://doi.org/10.1038/s42004-023-00924-3
  • Primary Citation Related Structures:
    8E9A

  • PubMed Abstract:

    Deoxyribozymes (DNAzymes) are in vitro evolved DNA sequences capable of catalyzing chemical reactions. The RNA-cleaving 10-23 DNAzyme was the first DNAzyme to be evolved and possesses clinical and biotechnical applications as a biosensor and a knockdown agent. DNAzymes do not require the recruitment of other components to cleave RNA and can turnover, thus they have a distinct advantage over other knockdown methods (siRNA, CRISPR, morpholinos). Despite this, a lack of structural and mechanistic information has hindered the optimization and application of the 10-23 DNAzyme. Here, we report a 2.7 Å crystal structure of the RNA-cleaving 10-23 DNAzyme in a homodimer conformation. Although proper coordination of the DNAzyme to substrate is observed along with intriguing patterns of bound magnesium ions, the dimer conformation likely does not capture the true catalytic form of the 10-23 DNAzyme.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Medicine, West Virginia University, Morgantown, WV, 20506, USA.

Macromolecule Content

  • Total Structure Weight: 73.5 kDa
  • Atom Count: 4,932
  • Modeled Residue Count: 448
  • Deposited Residue Count: 454
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Repair DNA polymerase X
A, B
175African swine fever virus BA71VMutation(s): 0
Gene Names: Ba71V-97O174L
EC: 2.7.7.7
UniProt
Find proteins for P42494 (African swine fever virus (strain Badajoz 1971 Vero-adapted))
Explore P42494
Go to UniProtKB:  P42494
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP42494
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA/RNA (52-MER)
C, D
52synthetic construct
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MG

Query on MG



Download:Ideal Coordinates CCD File
E [auth A]
K [auth B]
P [auth C]
S [auth D]
T [auth D]
E [auth A],
K [auth B],
P [auth C],
S [auth D],
T [auth D],
U [auth D]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
NA

Query on NA



Download:Ideal Coordinates CCD File
F [auth A]
G [auth A]
H [auth A]
I [auth A]
J [auth A]
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
L [auth B],
M [auth B],
N [auth B],
O [auth B],
Q [auth C],
R [auth C],
V [auth D]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free:  0.289 (Depositor), 0.289 (DCC)
  • R-Value Work:  0.255 (Depositor), 0.256 (DCC)
  • R-Value Observed: 0.257 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 114.829α = 90
b = 48.419β = 90
c = 139.845γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
iMOSFLMdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States5R01GM133857

Revision History  (Full details and data files)

  • Version 1.0: 2023-06-21
    Type: Initial release
  • Version 1.1: 2023-10-25
    Changes: Data collection
  • Version 1.2: 2024-03-13
    Changes: Source and taxonomy
  • Version 1.3: 2024-10-09
    Changes: Structure summary
