8E8I | pdb_00008e8i

Structures of HLA-B8E76C loaded with long peptides reveal novel features at the N-terminus of the groove


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.49 Å
  • R-Value Free:
    0.211 (Depositor), 0.211 (DCC)
  • R-Value Work:
    0.179 (Depositor), 0.180 (DCC)
  • R-Value Observed:
    0.181 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8E8I

This is version 1.3 of the entry. See complete history

Literature

Crystal structures of MHC class I complexes reveal the elusive intermediate conformations explored during peptide editing.

Li, L.Peng, X.Batliwala, M.Bouvier, M.

(2023) Nat Commun 14: 5020-5020

  • DOI: https://doi.org/10.1038/s41467-023-40736-6
  • Primary Citation Related Structures:
    8E13, 8E2Z, 8E8I, 8EC5

  • PubMed Abstract:

    Studies have suggested that MHC class I (MHC I) molecules fluctuate rapidly between numerous conformational states and these motions support peptide sampling. To date, MHC I intermediates are largely uncharacterized experimentally and remain elusive. Here, we present x-ray crystal structures of HLA-B8 loaded with 20mer peptides that show pronounced distortions at the N-terminus of the groove. Long stretches of N-terminal amino acid residues are missing in the electron density maps creating an open-ended groove. Our structures also reveal highly unusual features in MHC I-peptide interaction at the N-terminus of the groove. Molecular dynamics simulations indicate that the complexes have varying degrees of conformational flexibility in a manner consistent with the structures. We suggest that our structures have captured the remarkable molecular dynamics of MHC I-peptide interaction. The visualization of peptide-dependent conformational motions in MHC I is a major step forward in our conceptual understanding of dynamics in high-affinity peptide selection.


  • Organizational Affiliation
    • Department of Microbiology and Immunology, University of Illinois, Chicago, IL, 60612, USA.

Macromolecule Content

  • Total Structure Weight: 44.81 kDa
  • Atom Count: 3,696
  • Modeled Residue Count: 383
  • Deposited Residue Count: 384
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
MHC class I antigen276Homo sapiensMutation(s): 1
Gene Names: HLA-B
UniProt
Find proteins for Q5SS57 (Homo sapiens)
Explore Q5SS57
Go to UniProtKB:  Q5SS57
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SS57
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-2-microglobulin100Homo sapiensMutation(s): 0
Gene Names: B2MCDABP0092HDCMA22P
UniProt & NIH Common Fund Data Resources
Find proteins for P61769 (Homo sapiens)
Explore P61769
Go to UniProtKB:  P61769
PHAROS:  P61769
GTEx:  ENSG00000166710
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP61769
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
PHE-VAL-LYS-LYS-LYS-TYR-CYS-LEU8Human immunodeficiency virus 1Mutation(s): 0

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.49 Å
  • R-Value Free:  0.211 (Depositor), 0.211 (DCC)
  • R-Value Work:  0.179 (Depositor), 0.180 (DCC)
  • R-Value Observed: 0.181 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 50.645α = 90
b = 81.232β = 90
c = 110.179γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR01 AI114467

Revision History  (Full details and data files)

  • Version 1.0: 2023-07-26
    Type: Initial release
  • Version 1.1: 2024-02-07
    Changes: Data collection, Database references
  • Version 1.2: 2024-11-20
    Changes: Structure summary
  • Version 1.3: 2026-03-04
    Changes: Refinement description
