8E6U

Human TRPM2 ion channel in 1 mM F-dADPR

PDB DOI: https://doi.org/10.2210/pdb8E6U/pdb
EM Map EMD-27926: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): No
Membrane Protein: Yes PDBTM

Deposited: 2022-08-23 Released: 2024-08-14
Deposition Author(s): Wang, L., Fu, T.M., Xia, S., Wu, H.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.20 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

A unified mechanism for human TRPM2 activation, desensitization and inhibition

Wang, L., Fu, T.-M.

To be published.

Macromolecule Content

Total Structure Weight: 690.62 kDa
Atom Count: 43,388
Modelled Residue Count: 5,348
Deposited Residue Count: 6,012
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transient receptor potential cation channel subfamily M member 2	A, B, C, D	1,503	Homo sapiens	Mutation(s): 0 Gene Names: TRPM2, EREG1, KNP3, LTRPC2, TRPC7 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for O94759 (Homo sapiens) Explore O94759 Go to UniProtKB: O94759
PHAROS: O94759 GTEx: ENSG00000142185
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O94759
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
UOZ (Subject of Investigation/LOI) Query on UOZ Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth B] SDF format, chain H [auth B] SDF format, chain I [auth C] SDF format, chain J [auth C] SDF format, chain K [auth D] SDF format, chain L [auth D] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth B] MOL2 format, chain H [auth B] MOL2 format, chain I [auth C] MOL2 format, chain J [auth C] MOL2 format, chain K [auth D] MOL2 format, chain L [auth D] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth B] mmCIF format, chain H [auth B] mmCIF format, chain I [auth C] mmCIF format, chain J [auth C] mmCIF format, chain K [auth D] mmCIF format, chain L [auth D]	E [auth A] F [auth A] G [auth B] H [auth B] I [auth C] E [auth A], F [auth A], G [auth B], H [auth B], I [auth C], J [auth C], K [auth D], L [auth D]	[(2R,3S,5R)-5-(6-amino-8-phenyl-9H-purin-9-yl)-3-hydroxyoxolan-2-yl]methyl [(2R,3S,4S,5R)-3,4,5-trihydroxyoxolan-2-yl]methyl dihydrogen diphosphate (non-preferred name) C₂₁ H₂₇ N₅ O₁₃ P₂ HDAKJMFIHMDGRC-SXAIUVOJSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth C] Focus chain J [auth C] Focus chain K [auth D] Focus chain L [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth C] Focus chain J [auth C] Focus chain K [auth D] Focus chain L [auth D]
