8DNA | pdb_00008dna

Acidipropionibacterium acidipropionici encapsulin in a closed state at pH 3.0


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.77 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8DNA

This is version 1.1 of the entry. See complete history

Literature

Exploring the Extreme Acid Tolerance of a Dynamic Protein Nanocage.

Jones, J.A.Andreas, M.P.Giessen, T.W.

(2023) Biomacromolecules 24: 1388-1399

  • DOI: https://doi.org/10.1021/acs.biomac.2c01424
  • Primary Citation Related Structures:
    8DN9, 8DNA, 8DNL

  • PubMed Abstract:

    Encapsulins are microbial protein nanocages capable of efficient self-assembly and cargo enzyme encapsulation. Due to their favorable properties, including high thermostability, protease resistance, and robust heterologous expression, encapsulins have become popular bioengineering tools for applications in medicine, catalysis, and nanotechnology. Resistance against physicochemical extremes like high temperature and low pH is a highly desirable feature for many biotechnological applications. However, no systematic search for acid-stable encapsulins has been carried out, while the influence of pH on encapsulin shells has so far not been thoroughly explored. Here, we report on a newly identified encapsulin nanocage from the acid-tolerant bacterium Acidipropionibacterium acidipropionici . Using transmission electron microscopy, dynamic light scattering, and proteolytic assays, we demonstrate its extreme acid tolerance and resilience against proteases. We structurally characterize the novel nanocage using cryo-electron microscopy, revealing a dynamic five-fold pore that displays distinct "closed" and "open" states at neutral pH but only a singular "closed" state under strongly acidic conditions. Further, the "open" state exhibits the largest pore in an encapsulin shell reported to date. Non-native protein encapsulation capabilities are demonstrated, and the influence of external pH on internalized cargo is explored. Our results expand the biotechnological application range of encapsulin nanocages toward potential uses under strongly acidic conditions and highlight pH-responsive encapsulin pore dynamics.


  • Organizational Affiliation
    • Department of Biological Chemistry, University of Michigan Medical School, Ann Arbor, Michigan 48109-0624, United States.

Macromolecule Content

  • Total Structure Weight: 28.52 kDa
  • Atom Count: 2,007
  • Modeled Residue Count: 264
  • Deposited Residue Count: 264
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
29 kDa antigen cfp29264Acidipropionibacterium acidipropionici ATCC 4875Mutation(s): 0
Gene Names: PACID_10050
UniProt
Find proteins for K7RV67 (Acidipropionibacterium acidipropionici (strain ATCC 4875 / DSM 20272 / JCM 6432 / NBRC 12425 / NCIMB 8070 / 4))
Explore K7RV67
Go to UniProtKB:  K7RV67
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupK7RV67
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.77 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC3.3.1
MODEL REFINEMENTCoot8.9.6
MODEL REFINEMENTPHENIX1.19.2-4158

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35GM133325

Revision History  (Full details and data files)

  • Version 1.0: 2023-03-22
    Type: Initial release
  • Version 1.1: 2024-06-12
    Changes: Data collection
