8DL1 | pdb_00008dl1

BoGH13ASus-E523Q from Bacteroides ovatus bound to maltoheptaose


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.09 Å
  • R-Value Free:
    0.223 (Depositor), 0.227 (DCC)
  • R-Value Work:
    0.177 (Depositor), 0.185 (DCC)
  • R-Value Observed:
    0.179 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8DL1

This is version 1.2 of the entry. See complete history

Literature

BoGH13A Sus from Bacteroides ovatus represents a novel alpha-amylase used for Bacteroides starch breakdown in the human gut.

Brown, H.A.DeVeaux, A.L.Juliano, B.R.Photenhauer, A.L.Boulinguiez, M.Bornschein, R.E.Wawrzak, Z.Ruotolo, B.T.Terrapon, N.Koropatkin, N.M.

(2023) Cell Mol Life Sci 80: 232-232

  • DOI: https://doi.org/10.1007/s00018-023-04812-w
  • Primary Citation Related Structures:
    8DGE, 8DL1, 8DL2

  • PubMed Abstract:

    Members of the Bacteroidetes phylum in the human colon deploy an extensive number of proteins to capture and degrade polysaccharides. Operons devoted to glycan breakdown and uptake are termed polysaccharide utilization loci or PUL. The starch utilization system (Sus) is one such PUL and was initially described in Bacteroides thetaiotaomicron (Bt). BtSus is highly conserved across many species, except for its extracellular α-amylase, SusG. In this work, we show that the Bacteroides ovatus (Bo) extracellular α-amylase, BoGH13A Sus , is distinguished from SusG in its evolutionary origin and its domain architecture and by being the most prevalent form in Bacteroidetes Sus. BoGH13A Sus is the founding member of both a novel subfamily in the glycoside hydrolase family 13, GH13_47, and a novel carbohydrate-binding module, CBM98. The BoGH13A Sus CBM98-CBM48-GH13_47 architecture differs from the CBM58 embedded within the GH13_36 of SusG. These domains adopt a distinct spatial orientation and invoke a different association with the outer membrane. The BoCBM98 binding site is required for Bo growth on polysaccharides and optimal enzymatic degradation thereof. Finally, the BoGH13A Sus structure features bound Ca 2+ and Mn 2+ ions, the latter of which is novel for an α-amylase. Little is known about the impact of Mn 2+ on gut bacterial function, much less on polysaccharide consumption, but Mn 2+ addition to Bt expressing BoGH13A Sus specifically enhances growth on starch. Further understanding of bacterial starch degradation signatures will enable more tailored prebiotic and pharmaceutical approaches that increase starch flux to the gut.


  • Organizational Affiliation
    • Department of Microbiology and Immunology, University of Michigan Medical School, Ann Arbor, MI, 48109, USA. haleybr@umich.edu.

Macromolecule Content

  • Total Structure Weight: 350.81 kDa
  • Atom Count: 25,543
  • Modeled Residue Count: 2,839
  • Deposited Residue Count: 2,952
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Alpha amylase, catalytic domain protein
A, B, C, D
738Bacteroides ovatus ATCC 8483Mutation(s): 1
Gene Names: BACOVA_03514Bovatus_03803

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseE [auth G],
F [auth H],
G [auth I],
H [auth J],
I [auth K]
5N/A
Glycosylation Resources
GlyTouCan: G50146AM
GlyCosmos: G50146AM
Entity ID: 3
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseJ [auth L],
K [auth M]
3N/A
Glycosylation Resources
GlyTouCan: G96370VA
GlyCosmos: G96370VA
GlyGen: G96370VA
Entity ID: 4
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseL [auth N]4N/A
Glycosylation Resources
GlyTouCan: G87171PZ
GlyCosmos: G87171PZ
GlyGen: G87171PZ
Entity ID: 5
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-D-glucopyranose-(1-4)-[alpha-D-glucopyranose-(1-6)]alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseM [auth O]7N/A
Entity ID: 6
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-6)-[alpha-D-glucopyranose-(1-4)]alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseN [auth P]7N/A
Entity ID: 7
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-6)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseO [auth Q]6N/A
Entity ID: 8
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-D-glucopyranose-(1-6)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseP [auth R]5N/A
Glycosylation Resources
GlyTouCan: G15963LE
GlyCosmos: G15963LE

Small Molecules

Ligands 9 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
1PE

Query on 1PE



Download:Ideal Coordinates CCD File
JB [auth C]PENTAETHYLENE GLYCOL
C10 H22 O6
JLFNLZLINWHATN-UHFFFAOYSA-N
PGE

Query on PGE



Download:Ideal Coordinates CCD File
KB [auth C]TRIETHYLENE GLYCOL
C6 H14 O4
ZIBGPFATKBEMQZ-UHFFFAOYSA-N
PEG

Query on PEG



Download:Ideal Coordinates CCD File
UB [auth C]DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
AA [auth A]
AB [auth B]
AC [auth C]
BB [auth B]
BC [auth C]
AA [auth A],
AB [auth B],
AC [auth C],
BB [auth B],
BC [auth C],
CB [auth B],
DA [auth A],
DB [auth B],
EA [auth A],
EB [auth B],
FA [auth A],
FB [auth B],
FC [auth D],
GA [auth A],
GB [auth B],
HA [auth A],
HB [auth B],
HC [auth D],
IB [auth B],
IC [auth D],
JC [auth D],
KA [auth A],
KC [auth D],
LB [auth C],
MA [auth A],
MB [auth C],
NA [auth B],
NB [auth C],
OA [auth B],
OB [auth C],
PA [auth B],
PB [auth C],
Q [auth A],
QA [auth B],
RA [auth B],
S [auth A],
SA [auth B],
T [auth A],
TA [auth B],
TB [auth C],
U [auth A],
UA [auth B],
V [auth A],
VB [auth C],
W [auth A],
WB [auth C],
X [auth A],
XA [auth B],
XB [auth C],
Y [auth A],
YA [auth B],
YB [auth C],
Z [auth A],
ZA [auth B],
ZB [auth C]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
ACT

Query on ACT



Download:Ideal Coordinates CCD File
GC [auth D],
IA [auth A],
JA [auth A],
LA [auth A],
R [auth A]
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
MN

Query on MN



Download:Ideal Coordinates CCD File
CA [auth A],
DC [auth D],
RB [auth C],
WA [auth B]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
CA

Query on CA



Download:Ideal Coordinates CCD File
BA [auth A],
CC [auth D],
QB [auth C],
VA [auth B]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
EC [auth D]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA

Query on NA



Download:Ideal Coordinates CCD File
SB [auth C]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.09 Å
  • R-Value Free:  0.223 (Depositor), 0.227 (DCC)
  • R-Value Work:  0.177 (Depositor), 0.185 (DCC)
  • R-Value Observed: 0.179 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.68α = 90
b = 128.64β = 105.37
c = 149.76γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
PDB_EXTRACTdata extraction
xia2data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM118475
National Institutes of Health/National Center for Complementary and Integrative Health (NIH/NCCIH)United StatesAT011278

Revision History  (Full details and data files)

  • Version 1.0: 2023-05-24
    Type: Initial release
  • Version 1.1: 2023-09-20
    Changes: Data collection, Database references
  • Version 1.2: 2023-10-25
    Changes: Refinement description
