8DIF

Virtual screening for novel SARS-CoV-2 main protease non-covalent and covalent inhibitors


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.98 Å
  • R-Value Free: 0.294
  • R-Value Work: 0.240
  • R-Value Observed: 0.243

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Large library docking for novel SARS-CoV-2 main protease non-covalent and covalent inhibitors.

Fink, E.A.Bardine, C.Gahbauer, S.Singh, I.Detomasi, T.C.White, K.Gu, S.Wan, X.Chen, J.Ary, B.Glenn, I.O'Connell, J.O'Donnell, H.Fajtova, P.Lyu, J.Vigneron, S.Young, N.J.Kondratov, I.S.Alisoltani, A.Simons, L.M.Lorenzo-Redondo, R.Ozer, E.A.Hultquist, J.F.O'Donoghue, A.J.Moroz, Y.S.Taunton, J.Renslo, A.R.Irwin, J.J.Garcia-Sastre, A.Shoichet, B.K.Craik, C.S.

(2023) Protein Sci 32: e4712-e4712

  • DOI: https://doi.org/10.1002/pro.4712
  • Primary Citation of Related Structures:
    8DIB, 8DIC, 8DID, 8DIE, 8DIF, 8DIG, 8DIH, 8DII

  • PubMed Abstract:

    Antiviral therapeutics to treat SARS-CoV-2 are needed to diminish the morbidity of the ongoing COVID-19 pandemic. A well-precedented drug target is the main viral protease (M Pro ), which is targeted by an approved drug and by several investigational drugs. Emerging viral resistance has made new inhibitor chemotypes more pressing. Adopting a structure-based approach, we docked 1.2 billion non-covalent lead-like molecules and a new library of 6.5 million electrophiles against the enzyme structure. From these, 29 non-covalent and 11 covalent inhibitors were identified in 37 series, the most potent having an IC 50 of 29 and 20 μM, respectively. Several series were optimized, resulting in low micromolar inhibitors. Subsequent crystallography confirmed the docking predicted binding modes and may template further optimization. While the new chemotypes may aid further optimization of M Pro inhibitors for SARS-CoV-2, the modest success rate also reveals weaknesses in our approach for challenging targets like M Pro versus other targets where it has been more successful, and versus other structure-based techniques against M Pro itself.


  • Organizational Affiliation

    Department of Pharmaceutical Chemistry, University of California-San Francisco, San Francisco, California, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
3C-like proteinase nsp5
A, B
306Severe acute respiratory syndrome coronavirus 2Mutation(s): 0
Gene Names: rep1a-1b
EC: 3.4.22.69
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTD1
Go to UniProtKB:  P0DTD1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTD1
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.98 Å
  • R-Value Free: 0.294
  • R-Value Work: 0.240
  • R-Value Observed: 0.243
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 44.897α = 90
b = 53.624β = 101.15
c = 115.04γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling
MOLREPphasing
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other governmentUnited States--

Revision History  (Full details and data files)

  • Version 1.0: 2023-06-28
    Type: Initial release
  • Version 1.1: 2023-07-05
    Changes: Database references
  • Version 1.2: 2023-08-09
    Changes: Database references
  • Version 1.3: 2023-10-25
    Changes: Data collection, Refinement description
  • Version 1.4: 2024-11-20
    Changes: Structure summary
