8CP3

Apo-LarE in complex with AMP-PNP

PDB DOI: https://doi.org/10.2210/pdb8CP3/pdb

Classification: TRANSFERASE
Organism(s): Methanococcus maripaludis S2
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2023-03-01 Released: 2024-01-31
Deposition Author(s): Zecchin, P., Pecqueur, L., Golinelli-Pimpaneau, B.
Funding Organization(s): French National Research Agency

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.35 Å
R-Value Free: 0.250
R-Value Work: 0.232
R-Value Observed: 0.233

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Structure-based insights into the mechanism of [4Fe-4S]-dependent sulfur insertase LarE.

Zecchin, P., Pecqueur, L., Oltmanns, J., Velours, C., Schunemann, V., Fontecave, M., Golinelli-Pimpaneau, B.

(2024) Protein Sci 33: e4874-e4874

PubMed: 38100250 Search on PubMedSearch on PubMed Central
DOI: https://doi.org/10.1002/pro.4874
Primary Citation of Related Structures:
8CNZ, 8CP3, 8CP4

PubMed Abstract:
Several essential cellular metabolites, such as enzyme cofactors, contain sulfur atoms and their biosynthesis requires specific thiolation enzymes. LarE is an ATP-dependent sulfur insertase, which catalyzes the sequential conversion of the two carboxylate groups of the precursor of the lactate racemase cofactor into thiocarboxylates. Two types of LarE enzymes are known, one that uses a catalytic cysteine as a sacrificial sulfur donor, and the other one that uses a [4Fe-4S] cluster as a cofactor. Only the crystal structure of LarE from Lactobacillus plantarum (LpLarE) from the first class has been solved. We report here the crystal structure of LarE from Methanococcus maripaludis (MmLarE), belonging to the second class, in the cluster-free (apo-) and cluster-bound (holo-) forms. The structure of holo-MmLarE shows that the [4Fe-4S] cluster is chelated by three cysteines only, leaving an open coordination site on one Fe atom. Moreover, the fourth nonprotein-bonded iron atom was able to bind an anionic ligand such as a phosphate group or a chloride ion. Together with the spectroscopic analysis of holo-MmLarE and the previously reported biochemical investigations of holo-LarE from Thermotoga maritima, these crystal structures support the hypothesis of a reaction mechanism, in which the [4Fe-4S] cluster binds a hydrogenosulfide ligand in place of the chloride anion, thus generating a [4Fe-5S] intermediate, and transfers it to the substrate, as in the case of [4Fe-4S]-dependent tRNA thiolation enzymes.

Organizational Affiliation

Laboratoire de Chimie des Processus Biologiques, Collège de France, CNRS UMR 8829, Sorbonne Université, Paris cedex 05, France.

Macromolecule Content

Total Structure Weight: 64.16 kDa
Atom Count: 3,878
Modelled Residue Count: 495
Deposited Residue Count: 542
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
NAD_synthase domain-containing protein	A, B	271	Methanococcus maripaludis S2	Mutation(s): 0 Gene Names: MMP1239
UniProt
Find proteins for Q6LXV7 (Methanococcus maripaludis (strain DSM 14266 / JCM 13030 / NBRC 101832 / S2 / LL)) Explore Q6LXV7 Go to UniProtKB: Q6LXV7
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q6LXV7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ANP (Subject of Investigation/LOI) Query on ANP Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain G [auth B] MOL2 format, chain C [auth A] MOL2 format, chain G [auth B] mmCIF format, chain C [auth A] mmCIF format, chain G [auth B]	C [auth A], G [auth B]	PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER C₁₀ H₁₇ N₆ O₁₂ P₃ PVKSNHVPLWYQGJ-KQYNXXCUSA-N		Interactions Focus chain C [auth A] Focus chain G [auth B] Interactions & Density Focus chain C [auth A] Focus chain G [auth B]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain M [auth B] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B]	E [auth A] F [auth A] J [auth B] K [auth B] L [auth B] E [auth A], F [auth A], J [auth B], K [auth B], L [auth B], M [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain H [auth B] MOL2 format, chain H [auth B] mmCIF format, chain H [auth B]	H [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain H [auth B] Interactions & Density Focus chain H [auth B]
BME Query on BME Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain I [auth B] MOL2 format, chain D [auth A] MOL2 format, chain I [auth B] mmCIF format, chain D [auth A] mmCIF format, chain I [auth B]	D [auth A], I [auth B]	BETA-MERCAPTOETHANOL C₂ H₆ O S DGVVWUTYPXICAM-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain I [auth B] Interactions & Density Focus chain D [auth A] Focus chain I [auth B]
