8ADL

Cryo-EM structure of the SEA complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.95 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Cryo-EM structure of the SEA complex.

Tafur, L.Hinterndorfer, K.Gabus, C.Lamanna, C.Bergmann, A.Sadian, Y.Hamdi, F.Kyrilis, F.L.Kastritis, P.L.Loewith, R.

(2022) Nature 611: 399-404

  • DOI: https://doi.org/10.1038/s41586-022-05370-0
  • Primary Citation of Related Structures:
    8ADL, 8AE6

  • PubMed Abstract:

    The SEA complex (SEAC) is a growth regulator that acts as a GTPase-activating protein (GAP) towards Gtr1, a Rag GTPase that relays nutrient status to the Target of Rapamycin Complex 1 (TORC1) in yeast 1 . Functionally, the SEAC has been divided into two subcomplexes: SEACIT, which has GAP activity and inhibits TORC1, and SEACAT, which regulates SEACIT 2 . This system is conserved in mammals: the GATOR complex, consisting of GATOR1 (SEACIT) and GATOR2 (SEACAT), transmits amino acid 3 and glucose 4 signals to mTORC1. Despite its importance, the structure of SEAC/GATOR, and thus molecular understanding of its function, is lacking. Here, we solve the cryo-EM structure of the native eight-subunit SEAC. The SEAC has a modular structure in which a COPII-like cage corresponding to SEACAT binds two flexible wings, which correspond to SEACIT. The wings are tethered to the core via Sea3, which forms part of both modules. The GAP mechanism of GATOR1 is conserved in SEACIT, and GAP activity is unaffected by SEACAT in vitro. In vivo, the wings are essential for recruitment of the SEAC to the vacuole, primarily via the EGO complex. Our results indicate that rather than being a direct inhibitor of SEACIT, SEACAT acts as a scaffold for the binding of TORC1 regulators.


  • Organizational Affiliation

    Department of Molecular and Cellular Biology, University of Geneva, Geneva, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Maintenance of telomere capping protein 5A [auth C],
I [auth Q]
1,148Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for Q03897 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q03897
Go to UniProtKB:  Q03897
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ03897
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Nucleoporin SEH1349Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P53011 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P53011
Go to UniProtKB:  P53011
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53011
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
SEH-associated protein 4C [auth G],
F [auth B],
K [auth O],
N [auth J]
1,038Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P38164 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38164
Go to UniProtKB:  P38164
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38164
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Protein transport protein SEC13D [auth H],
L [auth P]
297Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for Q04491 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q04491
Go to UniProtKB:  Q04491
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ04491
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Restriction of telomere capping protein 1E [auth A],
M [auth I]
1,341Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for Q08281 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q08281
Go to UniProtKB:  Q08281
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08281
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Nitrogen permease regulator 3Q [auth U],
T [auth V]
1,146Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P38742 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38742
Go to UniProtKB:  P38742
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38742
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Vacuolar membrane-associated protein IML1R [auth W],
U [auth X]
1,584Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P47170 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P47170
Go to UniProtKB:  P47170
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP47170
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Nitrogen permease regulator 2S,
V [auth T]
615Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P39923 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P39923
Go to UniProtKB:  P39923
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39923
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
AA [auth G]
BA [auth G]
CA [auth G]
DA [auth A]
EA [auth A]
AA [auth G],
BA [auth G],
CA [auth G],
DA [auth A],
EA [auth A],
FA [auth A],
GA [auth B],
HA [auth B],
IA [auth B],
JA [auth B],
KA [auth Q],
LA [auth Q],
MA [auth Q],
NA [auth O],
OA [auth O],
PA [auth O],
QA [auth O],
RA [auth I],
SA [auth I],
TA [auth I],
UA [auth J],
VA [auth J],
W [auth C],
WA [auth J],
X [auth C],
XA [auth J],
Y [auth C],
Z [auth G]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.95 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC3.3.2
MODEL REFINEMENTPHENIX1.2

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European Molecular Biology Organization (EMBO)European UnionALTF 79-2019
European Research Council (ERC)European UnionTENDO

Revision History  (Full details and data files)

  • Version 1.0: 2022-11-02
    Type: Initial release
  • Version 1.1: 2022-11-09
    Changes: Database references
  • Version 1.2: 2022-11-16
    Changes: Database references
  • Version 1.3: 2022-11-23
    Changes: Database references
  • Version 1.4: 2023-05-10
    Changes: Database references, Refinement description, Structure summary
  • Version 1.5: 2024-07-24
    Changes: Data collection, Refinement description
