7ZN2

Tail tip of siphophage T5 : full complex after interaction with its bacterial receptor FhuA


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.29 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural basis of bacteriophage T5 infection trigger and E. coli cell wall perforation.

Linares, R.Arnaud, C.A.Effantin, G.Darnault, C.Epalle, N.H.Boeri Erba, E.Schoehn, G.Breyton, C.

(2023) Sci Adv 9: eade9674-eade9674

  • DOI: https://doi.org/10.1126/sciadv.ade9674
  • Primary Citation of Related Structures:
    7QG9, 7ZHJ, 7ZLV, 7ZN2, 7ZN4, 7ZQB, 7ZQP

  • PubMed Abstract:

    Most bacteriophages present a tail allowing host recognition, cell wall perforation, and viral DNA channeling from the capsid to the infected bacterium cytoplasm. The majority of tailed phages bear a long flexible tail ( Siphoviridae ) at the tip of which receptor binding proteins (RBPs) specifically interact with their host, triggering infection. In siphophage T5, the unique RBP is located at the extremity of a central fiber. We present the structures of T5 tail tip, determined by cryo-electron microscopy before and after interaction with its E. coli receptor, FhuA, reconstituted into nanodisc. These structures bring out the important conformational changes undergone by T5 tail tip upon infection, which include bending of T5 central fiber on the side of the tail tip, tail anchoring to the membrane, tail tube opening, and formation of a transmembrane channel. The data allow to detail the first steps of an otherwise undescribed infection mechanism.


  • Organizational Affiliation

    Univ. Grenoble Alpes, CNRS, CEA, IBS, Grenoble F-38000, France.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Probable baseplate hub proteinA [auth d],
E [auth c],
I [auth b]
949Escherichia phage T5Mutation(s): 0
UniProt
Find proteins for Q6QGE9 (Escherichia phage T5)
Explore Q6QGE9
Go to UniProtKB:  Q6QGE9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6QGE9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Pore-forming tail tip protein pb2B [auth j],
C [auth h],
D [auth i]
1,219Escherichia phage T5Mutation(s): 0
UniProt
Find proteins for Q6QGE7 (Escherichia phage T5)
Explore Q6QGE7
Go to UniProtKB:  Q6QGE7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6QGE7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Straight fiber protein pb4F [auth f],
G [auth e],
H [auth g]
688Escherichia phage T5Mutation(s): 0
UniProt
Find proteins for Q6QGF0 (Escherichia phage T5)
Explore Q6QGF0
Go to UniProtKB:  Q6QGF0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6QGF0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
L-shaped tail fiber protein p132140Escherichia phage T5Mutation(s): 0
UniProt
Find proteins for Q7Y5D9 (Escherichia phage T5)
Explore Q7Y5D9
Go to UniProtKB:  Q7Y5D9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7Y5D9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Minor tail proteinK [auth I],
Q [auth H],
Z [auth G]
298Escherichia phage T5Mutation(s): 0
UniProt
Find proteins for Q6QGE3 (Escherichia phage T5)
Explore Q6QGE3
Go to UniProtKB:  Q6QGE3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6QGE3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Distal tail protein204Escherichia phage T5Mutation(s): 0
UniProt
Find proteins for Q6QGE8 (Escherichia phage T5)
Explore Q6QGE8
Go to UniProtKB:  Q6QGE8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6QGE8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Tail tube protein464Escherichia phage T5Mutation(s): 0
UniProt
Find proteins for Q6QGE2 (Escherichia phage T5)
Explore Q6QGE2
Go to UniProtKB:  Q6QGE2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6QGE2
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.29 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX
MODEL REFINEMENTCoot
RECONSTRUCTIONRELION3.0/3.1

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Agence Nationale de la Recherche (ANR)FranceANR-16-CE11-0027
Agence Nationale de la Recherche (ANR)FranceANR-21-CE11-0023

Revision History  (Full details and data files)

  • Version 1.0: 2023-02-08
    Type: Initial release
  • Version 1.1: 2023-07-05
    Changes: Database references
