7QOH

Unique vertex of the phicrAss001 virion with C5 symmetry imposed


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.32 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Structural atlas of a human gut crassvirus.

Bayfield, O.W.Shkoporov, A.N.Yutin, N.Khokhlova, E.V.Smith, J.L.R.Hawkins, D.E.D.P.Koonin, E.V.Hill, C.Antson, A.A.

(2023) Nature 617: 409-416

  • DOI: https://doi.org/10.1038/s41586-023-06019-2
  • Primary Citation of Related Structures:
    7QOF, 7QOG, 7QOH, 7QOI, 7QOJ, 7QOK, 7QOL

  • PubMed Abstract:

    CrAssphage and related viruses of the order Crassvirales (hereafter referred to as crassviruses) were originally discovered by cross-assembly of metagenomic sequences. They are the most abundant viruses in the human gut, are found in the majority of individual gut viromes, and account for up to 95% of the viral sequences in some individuals 1-4 . Crassviruses are likely to have major roles in shaping the composition and functionality of the human microbiome, but the structures and roles of most of the virally encoded proteins are unknown, with only generic predictions resulting from bioinformatic analyses 4,5 . Here we present a cryo-electron microscopy reconstruction of Bacteroides intestinalis virus ΦcrAss001 6 , providing the structural basis for the functional assignment of most of its virion proteins. The muzzle protein forms an assembly about 1 MDa in size at the end of the tail and exhibits a previously unknown fold that we designate the 'crass fold', that is likely to serve as a gatekeeper that controls the ejection of cargos. In addition to packing the approximately 103 kb of virus DNA, the ΦcrAss001 virion has extensive storage space for virally encoded cargo proteins in the capsid and, unusually, within the tail. One of the cargo proteins is present in both the capsid and the tail, suggesting a general mechanism for protein ejection, which involves partial unfolding of proteins during their extrusion through the tail. These findings provide a structural basis for understanding the mechanisms of assembly and infection of these highly abundant crassviruses.


  • Organizational Affiliation

    York Structural Biology Laboratory, Department of Chemistry, University of York, York, UK. oliver.bayfield@york.ac.uk.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Major capsid protein gp32
A, B, C, D, E
A, B, C, D, E, F
504Bacteroides phage crAss001Mutation(s): 0
UniProt
Find proteins for A0A385DVU6 (Bacteroides phage crAss001)
Explore A0A385DVU6
Go to UniProtKB:  A0A385DVU6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A385DVU6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Auxiliary capsid protein gp36G [auth a],
H [auth b],
I [auth d],
J [auth e],
K [auth f]
333Bacteroides phage crAss001Mutation(s): 0
UniProt
Find proteins for A0A385DVS7 (Bacteroides phage crAss001)
Explore A0A385DVS7
Go to UniProtKB:  A0A385DVS7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A385DVS7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Portal vertex capsid protein gp57L [auth g],
M [auth h]
104Bacteroides phage crAss001Mutation(s): 0
UniProt
Find proteins for A0A385DTA3 (Bacteroides phage crAss001)
Explore A0A385DTA3
Go to UniProtKB:  A0A385DTA3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A385DTA3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Head fiber trimer protein gp21N [auth i],
O [auth j],
P [auth k]
97Bacteroides phage crAss001Mutation(s): 0
UniProt
Find proteins for A0A385DTC5 (Bacteroides phage crAss001)
Explore A0A385DTC5
Go to UniProtKB:  A0A385DTC5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A385DTC5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Portal protein gp20Q [auth l],
R [auth m]
806Bacteroides phage crAss001Mutation(s): 0
UniProt
Find proteins for A0A385DT68 (Bacteroides phage crAss001)
Explore A0A385DT68
Go to UniProtKB:  A0A385DT68
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A385DT68
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.32 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.1
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom--

Revision History  (Full details and data files)

  • Version 1.0: 2023-03-29
    Type: Initial release
  • Version 1.1: 2023-05-03
    Changes: Database references
  • Version 1.2: 2023-05-17
    Changes: Database references
  • Version 1.3: 2023-05-24
    Changes: Database references
  • Version 1.4: 2024-10-16
    Changes: Data collection, Structure summary
