7QIA

Structure of apo-EleNRMT in complex with two nanobodies at 3.5A


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural and functional properties of a magnesium transporter of the SLC11/NRAMP family.

Ramanadane, K.Straub, M.S.Dutzler, R.Manatschal, C.

(2022) Elife 11

  • DOI: https://doi.org/10.7554/eLife.74589
  • Primary Citation of Related Structures:
    7QIA, 7QIC, 7QJI, 7QJJ

  • PubMed Abstract:

    Members of the ubiquitous SLC11/NRAMP family catalyze the uptake of divalent transition metal ions into cells. They have evolved to efficiently select these trace elements from a large pool of Ca 2+ and Mg 2+ , which are both orders of magnitude more abundant, and to concentrate them in the cytoplasm aided by the cotransport of H + serving as energy source. In the present study, we have characterized a member of a distant clade of the family found in prokaryotes, termed NRMTs, that were proposed to function as transporters of Mg 2+ . The protein transports Mg 2+ and Mn 2+ but not Ca 2+ by a mechanism that is not coupled to H + . Structures determined by cryo-EM and X-ray crystallography revealed a generally similar protein architecture compared to classical NRAMPs, with a restructured ion binding site whose increased volume provides suitable interactions with ions that likely have retained much of their hydration shell.


  • Organizational Affiliation

    Department of Biochemistry, University of Zurich, Zurich, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Divalent metal cation transporter438Eggerthella lentaMutation(s): 11
Gene Names: C1853_09580C1871_08405
Membrane Entity: Yes
UniProt
Find proteins for C8WJ67 (Eggerthella lenta (strain ATCC 25559 / DSM 2243 / CCUG 17323 / JCM 9979 / KCTC 3265 / NCTC 11813 / VPI 0255 / 1899 B))
Explore C8WJ67
Go to UniProtKB:  C8WJ67
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC8WJ67
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Nanobody 1B [auth C]119synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Nanobody 2C [auth B]125synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC3.2
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Swiss National Science FoundationSwitzerland--

Revision History  (Full details and data files)

  • Version 1.0: 2021-12-29
    Type: Initial release
  • Version 1.1: 2022-02-02
    Changes: Database references
  • Version 1.2: 2024-10-23
    Changes: Data collection, Structure summary
