7PC5

The third PDZ domain of PDZD7 complexed with the PDZ-binding motif of EXOC4


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.188
  • R-Value Work: 0.166
  • R-Value Observed: 0.167

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

A scalable strategy to solve structures of PDZ domains and their complexes.

Cousido-Siah, A.Carneiro, L.Kostmann, C.Ecsedi, P.Nyitray, L.Trave, G.Gogl, G.

(2022) Acta Crystallogr D Struct Biol 78: 509-516

  • DOI: https://doi.org/10.1107/S2059798322001784
  • Primary Citation of Related Structures:
    7PC3, 7PC4, 7PC5, 7PC7, 7PC8, 7PC9, 7PCB, 7QQL, 7QQM, 7QQN

  • PubMed Abstract:

    The human PDZome represents one of the largest globular domain families in the human proteome, with 266 instances. These globular domains typically interact with C-terminal peptide motifs found in thousands of human proteins. Despite previous efforts, not all PDZ domains have experimentally solved structures and most of their complexes remain to be solved. Here, a simple and cost-effective strategy is proposed for the crystallization of PDZ domains and their complexes. A human annexin A2 fusion tag was used as a crystallization chaperone and the structures of nine PDZ domains were solved, including five domains that had not yet been solved. Finally, these novel experimental structures were compared with AlphaFold predictions and it is speculated how predictions and experimental methods could cooperate in order to investigate the structural landscapes of entire domain families and interactomes.


  • Organizational Affiliation

    Équipe Labellisée Ligue 2015, Département de Biologie Structurale Intégrative, Institut de Génétique et de Biologie Moléculaire et Cellulaire (IGBMC), INSERM U1258/CNRS UMR 7104/Université de Strasbourg, 1 Rue Laurent Fries, BP 10142, 67404 Illkirch, France.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
PDZ domain-containing protein 7,Annexin A2420Homo sapiensMutation(s): 0
Gene Names: PDZD7PDZK7ANXA2ANX2ANX2L4CAL1HLPC2D
UniProt & NIH Common Fund Data Resources
Find proteins for Q9H5P4 (Homo sapiens)
Explore Q9H5P4
Go to UniProtKB:  Q9H5P4
PHAROS:  Q9H5P4
GTEx:  ENSG00000186862
Find proteins for P07355 (Homo sapiens)
Explore P07355
Go to UniProtKB:  P07355
PHAROS:  P07355
GTEx:  ENSG00000182718
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP07355Q9H5P4
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Exocyst complex component 410Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q96A65 (Homo sapiens)
Explore Q96A65
Go to UniProtKB:  Q96A65
PHAROS:  Q96A65
GTEx:  ENSG00000131558
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ96A65
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.188
  • R-Value Work: 0.166
  • R-Value Observed: 0.167
  • Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 54.11α = 90
b = 60.35β = 90
c = 181.68γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-20
    Type: Initial release
  • Version 1.1: 2024-01-31
    Changes: Data collection, Refinement description
