7FVE

PanDDA analysis group deposition -- PHIP in complex with Z488932160

PDB DOI: https://doi.org/10.2210/pdb7FVE/pdb
Deposition Group: G_1002265 (changed state) ExploreG_1002265

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-03-09 Released: 2023-03-29
Deposition Author(s): Grosjean, H., Tomlinson, C., Bradshaw, W.J., Koekemoer, L., Krojer, T., Fearon, D., Biggin, P.C., von Delft, F.
Funding Organization(s): Wellcome Trust

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.19 Å
R-Value Free: 0.197
R-Value Work: 0.173
R-Value Observed: 0.174

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

PanDDA analysis group deposition

Grosjean, H., Tomlinson, C., Bradshaw, W.J., Koekemoer, L., Krojer, T., Fearon, D., Biggin, P.C., von Delft, F.

To be published.

Macromolecule Content

Total Structure Weight: 18.08 kDa
Atom Count: 1,278
Modelled Residue Count: 121
Deposited Residue Count: 149
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PH-interacting protein	A	149	Homo sapiens	Mutation(s): 0 Gene Names: PHIP, DCAF14, WDR11
UniProt & NIH Common Fund Data Resources
Find proteins for Q8WWQ0 (Homo sapiens) Go to UniProtKB: Q8WWQ0
PHAROS: Q8WWQ0 GTEx: ENSG00000146247
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZMN (Subject of Investigation/LOI) Query on ZMN Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	4-(5-bromofuran-2-carbonyl)-N-[3-(3-methylphenoxy)propyl]piperazine-1-carboxamide C₂₀ H₂₄ Br N₃ O₄ SCRILDURHLVTAB-UHFFFAOYSA-N		Interactions Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.19 Å
R-Value Free: 0.197
R-Value Work: 0.173
R-Value Observed: 0.174
Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 81.985	α = 90
b = 27.528	β = 100.15
c = 56.419	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
REFMAC	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2023-03-29

Deposition Author(s):

Funding Organization	Location	Grant Number
Wellcome Trust	United Kingdom	None

Revision History (Full details and data files)

Version 1.0: 2023-03-29
Type: Initial release
Version 1.1: 2024-05-22
Changes: Data collection
