7FV3

PanDDA analysis group deposition -- PHIP in complex with Z4912742924

• PDB DOI: https://doi.org/10.2210/pdb7FV3/pdb
• Deposition Group: G_1002265 (changed state) ExploreG_1002265

• Classification: SIGNALING PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2023-03-09 Released: 2023-03-29
• Deposition Author(s): Grosjean, H., Tomlinson, C., Bradshaw, W.J., Koekemoer, L., Krojer, T., Fearon, D., Biggin, P.C., von Delft, F.
• Funding Organization(s): Wellcome Trust

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.15 Å
• R-Value Free: 0.190
• R-Value Work: 0.179
• R-Value Observed: 0.179

Literature

PanDDA analysis group deposition

Grosjean, H., Tomlinson, C., Bradshaw, W.J., Koekemoer, L., Krojer, T., Fearon, D., Biggin, P.C., von Delft, F.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 17.92 kDa
• Atom Count: 1,221
• Modelled Residue Count: 120
• Deposited Residue Count: 149
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PH-interacting protein	A	149	Homo sapiens	Mutation(s): 0  Gene Names: PHIP, DCAF14, WDR11
UniProt & NIH Common Fund Data Resources
Find proteins for Q8WWQ0 (Homo sapiens) Explore Q8WWQ0  Go to UniProtKB:  Q8WWQ0
PHAROS:  Q8WWQ0 GTEx:  ENSG00000146247

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZKL (Subject of Investigation/LOI)	B [auth A]	(2R)-N-butyl-4-(furan-2-carbonyl)-2-methylpiperazine-1-carboxamide C15 H23 N3 O3 HESHQILVHQSCOB-GFCCVEGCSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.15 Å
• R-Value Free: 0.190
• R-Value Work: 0.179
• R-Value Observed: 0.179
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 81.8	α = 90
b = 27.434	β = 99.97
c = 56.297	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
REFMAC	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-03-29
Deposition Author(s): Grosjean, H., Tomlinson, C., Bradshaw, W.J., Koekemoer, L., Krojer, T., Fearon, D., Biggin, P.C., von Delft, F.

---

Funding Organization	Location	Grant Number
Wellcome Trust	United Kingdom	None

Revision History

• Version 1.0: 2023-03-29
  Type: Initial release

• Version 1.1: 2024-05-22
  Changes: Data collection
