7ZQU | pdb_00007zqu

A fast recovering full-length LOV protein (DsLOV) from the marine phototrophic bacterium Dinoroseobacter shibae (Dark state) - C72A mutant

PDB DOI: https://doi.org/10.2210/pdb7ZQU/pdb

Classification: SIGNALING PROTEIN
Organism(s): Dinoroseobacter shibae DFL 12 = DSM 16493
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): Yes

Deposited: 2022-05-03 Released: 2023-05-17
Deposition Author(s): Batra-Safferling, R., Granzin, J.
Funding Organization(s): German Federal Ministry for Education and Research

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free:
0.205 (Depositor), 0.208 (DCC)
R-Value Work:
0.188 (Depositor), 0.189 (DCC)
R-Value Observed:
0.189 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7ZQU

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

A fast recovering full-length LOV protein (DsLOV) from the marine phototrophic bacterium Dinoroseobacter shibae (Dark state) - C72A mutant

Batra-Safferling, R., Granzin, J.

To be published.

Macromolecule Content

Total Structure Weight: 17.29 kDa
Atom Count: 1,004
Modeled Residue Count: 117
Deposited Residue Count: 146
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative blue-light photoreceptor	A	146	Dinoroseobacter shibae DFL 12 = DSM 16493	Mutation(s): 1 Gene Names: Dshi_2006
UniProt
Find proteins for A8LP63 (Dinoroseobacter shibae (strain DSM 16493 / NCIMB 14021 / DFL 12)) Explore A8LP63 Go to UniProtKB: A8LP63
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A8LP63
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FMN (Subject of Investigation/LOI) Query on FMN Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	FLAVIN MONONUCLEOTIDE C₁₇ H₂₁ N₄ O₉ P FVTCRASFADXXNN-SCRDCRAPSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.205 (Depositor), 0.208 (DCC)
R-Value Work: 0.188 (Depositor), 0.189 (DCC)
R-Value Observed: 0.189 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 91.454	α = 90
b = 28.21	β = 119.397
c = 48.018	γ = 90

Software Package:

Software Name	Purpose
MxCuBE	data collection
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-05-17

Deposition Author(s):

Batra-Safferling, R.

Funding Organization	Location	Grant Number
German Federal Ministry for Education and Research	Germany	FKZ 031A16

Revision History (Full details and data files)

Version 1.0: 2023-05-17
Type: Initial release
Version 1.1: 2024-02-07
Changes: Data collection, Refinement description
