7ZHL | pdb_00007zhl

Salmonella enterica Rhs1 C-terminal toxin TreTu


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:
    0.226 (Depositor), 0.224 (DCC)
  • R-Value Work:
    0.192 (Depositor), 0.194 (DCC)
  • R-Value Observed:
    0.194 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7ZHL

This is version 1.3 of the entry. See complete history

Literature

Salmonella antibacterial Rhs polymorphic toxin inhibits translation through ADP-ribosylation of EF-Tu P-loop.

Jurenas, D.Rey, M.Byrne, D.Chamot-Rooke, J.Terradot, L.Cascales, E.

(2022) Nucleic Acids Res 50: 13114-13127

  • DOI: https://doi.org/10.1093/nar/gkac1162
  • Primary Citation Related Structures:
    7ZHL, 7ZHM

  • PubMed Abstract:

    Rearrangement hot spot (Rhs) proteins are members of the broad family of polymorphic toxins. Polymorphic toxins are modular proteins composed of an N-terminal region that specifies their mode of secretion into the medium or into the target cell, a central delivery module, and a C-terminal domain that has toxic activity. Here, we structurally and functionally characterize the C-terminal toxic domain of the antibacterial Rhsmain protein, TreTu, which is delivered by the type VI secretion system of Salmonella enterica Typhimurium. We show that this domain adopts an ADP-ribosyltransferase fold and inhibits protein synthesis by transferring an ADP-ribose group from NAD+ to the elongation factor Tu (EF-Tu). This modification is specifically placed on the side chain of the conserved D21 residue located on the P-loop of the EF-Tu G-domain. Finally, we demonstrate that the TriTu immunity protein neutralizes TreTu activity by acting like a lid that closes the catalytic site and traps the NAD+.


  • Organizational Affiliation
    • Laboratoire d'Ingénierie des Systèmes Macromoléculaires (LISM), Institut de Microbiologie, Bioénergies et Biotechnologie (IM2B), Aix-Marseille Université, CNRS, UMR 7255, 13009 Marseille, France.

Macromolecule Content

  • Total Structure Weight: 25.06 kDa
  • Atom Count: 1,708
  • Modeled Residue Count: 225
  • Deposited Residue Count: 232
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
RHS repeat protein
A, B
116Salmonella enterica subsp. enterica serovar TyphimuriumMutation(s): 0
Gene Names: D5823_18215G0J71_10035G0K31_21120
UniProt
Find proteins for Q8ZRL0 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720))
Explore Q8ZRL0
Go to UniProtKB:  Q8ZRL0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8ZRL0
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:  0.226 (Depositor), 0.224 (DCC)
  • R-Value Work:  0.192 (Depositor), 0.194 (DCC)
  • R-Value Observed: 0.194 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 51.546α = 90
b = 66.366β = 90
c = 67.7γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
SCALAdata scaling
AutoSolphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Agence Nationale de la Recherche (ANR)FranceANR-17-CE11-0039
Agence Nationale de la Recherche (ANR)FranceANR-20-CE11-0017

Revision History  (Full details and data files)

  • Version 1.0: 2022-11-23
    Type: Initial release
  • Version 1.1: 2022-12-28
    Changes: Database references
  • Version 1.2: 2023-01-18
    Changes: Database references
  • Version 1.3: 2024-06-19
    Changes: Data collection, Refinement description
