7ZE1

Tribolium castaneum hexamerin 2


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Polyelectrolyte coating of cryo-EM grids improves lateral distribution and prevents aggregation of macromolecules.

Hrebik, D.Gondova, M.Valentova, L.Fuzik, T.Pridal, A.Novacek, J.Plevka, P.

(2022) Acta Crystallogr D Struct Biol 78: 1337-1346

  • DOI: https://doi.org/10.1107/S2059798322009299
  • Primary Citation of Related Structures:
    7ZE1, 7ZFW, 7ZG7

  • PubMed Abstract:

    Cryo-electron microscopy (cryo-EM) is one of the primary methods used to determine the structures of macromolecules and their complexes. With the increased availability of cryo-electron microscopes, the preparation of high-quality samples has become a bottleneck in the cryo-EM structure-determination pipeline. Macromolecules can be damaged during the purification or preparation of vitrified samples for cryo-EM, making them prone to binding to the grid support, to aggregation or to the adoption of preferential orientations at the air-water interface. Here, it is shown that coating cryo-EM grids with a negatively charged polyelectrolyte, such as single-stranded DNA, before applying the sample reduces the aggregation of macromolecules and improves their distribution. The single-stranded DNA-coated grids enabled the determination of high-resolution structures from samples that aggregated on conventional grids. The polyelectrolyte coating reduces the diffusion of macromolecules and thus may limit the negative effects of the contact of macromolecules with the grid support and blotting paper, as well as of the shear forces on macromolecules during grid blotting. Coating grids with polyelectrolytes can readily be employed in any laboratory dealing with cryo-EM sample preparation, since it is fast, simple, inexpensive and does not require specialized equipment.


  • Organizational Affiliation

    Central European Institute of Technology, Masaryk University, Kamenice 5, 625 00 Brno, Czech Republic.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Larval serum protein 1 gamma chain-like Protein698Tribolium castaneumMutation(s): 0
UniProt
Find proteins for D6WUQ9 (Tribolium castaneum)
Explore D6WUQ9
Go to UniProtKB:  D6WUQ9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD6WUQ9
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.19
RECONSTRUCTIONRELION3.1

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Czech Science FoundationCzech RepublicGX19-25982X
European Regional Development FundEuropean UnionCZ.1.05/1.1.00/02.0070
Ministry of Education (MoE, Czech Republic)Czech RepublicLM2011033
Ministry of Education (MoE, Czech Republic)Czech RepublicLM2015043

Revision History  (Full details and data files)

  • Version 1.0: 2022-11-23
    Type: Initial release
  • Version 1.1: 2024-07-24
    Changes: Data collection
