7YTP

TLR7 in complex with an inhibitor

PDB DOI: https://doi.org/10.2210/pdb7YTP/pdb
EM Map EMD-34091: EMDB EMDataResource

Classification: IMMUNE SYSTEM
Organism(s): Macaca mulatta
Expression System: Drosophila melanogaster
Mutation(s): Yes

Deposited: 2022-08-15 Released: 2023-11-15
Deposition Author(s): Zhang, Z., Ohto, U., Shimizu, T.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.77 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

TLR7 in complex with an inhibitor

Zhang, Z., Shimizu, T.

To be published.

Macromolecule Content

Total Structure Weight: 228.65 kDa
Atom Count: 12,178
Modelled Residue Count: 1,462
Deposited Residue Count: 1,950
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Toll-like receptor 7	A, B	975	Macaca mulatta	Mutation(s): 10 Gene Names: TLR7
UniProt
Find proteins for B3Y653 (Macaca mulatta) Explore B3Y653 Go to UniProtKB: B3Y653
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	B3Y653
Glycosylation
Glycosylation Sites: 8	Glycosylation Focus chain A Focus chain B
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C, D, E, F, G C, D, E, F, G, H	2		N-Glycosylation	Interactions Focus chain C Focus chain D Focus chain E Focus chain F Focus chain G Focus chain H Interactions & Density Focus chain C Focus chain D Focus chain E Focus chain F Focus chain G Focus chain H
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
JRI (Subject of Investigation/LOI) Query on JRI Download Ideal Coordinates CCD File SDF format, chain N [auth A] SDF format, chain T [auth B] MOL2 format, chain N [auth A] MOL2 format, chain T [auth B] mmCIF format, chain N [auth A] mmCIF format, chain T [auth B]	N [auth A], T [auth B]	(2R,6R)-4-(8-cyanoquinolin-5-yl)-N-[(3S,4R)-4-fluoranylpyrrolidin-3-yl]-6-methyl-morpholine-2-carboxamide C₂₀ H₂₂ F N₅ O₂ BLEGXEJTJXNGSC-GMLZMKKNSA-N		Interactions Focus chain N [auth A] Focus chain T [auth B] Interactions & Density Focus chain N [auth A] Focus chain T [auth B]
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B]	I [auth A] J [auth A] K [auth A] L [auth A] M [auth A] I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], O [auth B], P [auth B], Q [auth B], R [auth B], S [auth B]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B]
