7YRN | pdb_00007yrn

Cyro-EM structure of HCMV glycoprotein B in complex with 1B03 Fab

PDB DOI: https://doi.org/10.2210/pdb7YRN/pdb
EM Map EMD-34063: EMDB EMDataResource

Classification: VIRAL PROTEIN/IMMUNE SYSTEM
Organism(s): Human betaherpesvirus 5, Homo sapiens
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2022-08-10 Released: 2023-08-16
Deposition Author(s): Wang, H., Zhu, S., Liao, H.
Funding Organization(s): Other government

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.99 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7YRN

This is version 1.2 of the entry. See complete history.

Literature

Cyro-EM structure of HCMV glycoprotein B in complex with 1B03 Fab

Wu, C., Wang, H., Zhu, S., Liao, H.

To be published.

Macromolecule Content

Total Structure Weight: 395.32 kDa
Atom Count: 16,080
Modeled Residue Count: 1,977
Deposited Residue Count: 3,504
Unique protein chains: 3

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Envelope glycoprotein B	A, D [auth B], G [auth C]	731	Human betaherpesvirus 5	Mutation(s): 0 Gene Names: UL55, gB
UniProt
Find proteins for B9VXM4 (Human cytomegalovirus (strain Towne)) Explore B9VXM4 Go to UniProtKB: B9VXM4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	B9VXM4
Glycosylation
Glycosylation Sites: 3	Glycosylation Focus chain A Focus chain D [auth B] Focus chain G [auth C]
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
1B03 Fab antibody Heavy Chain	B [auth D], E [auth F], H	223	Homo sapiens	Mutation(s): 0

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
1B03 Fab antibody Light Chain	C [auth E], F [auth G], I	214	Homo sapiens	Mutation(s): 0

Oligosaccharides

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	J, K, L	2		N-Glycosylation	Interactions Focus chain J Focus chain K Focus chain L Interactions & Density Focus chain J Focus chain K Focus chain L
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download:Ideal Coordinates CCD File SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth C] SDF format, chain R [auth C] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth C] MOL2 format, chain R [auth C] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth C] mmCIF format, chain R [auth C]	M [auth A] N [auth A] O [auth B] P [auth B] Q [auth C] M [auth A], N [auth A], O [auth B], P [auth B], Q [auth C], R [auth C]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth C] Focus chain R [auth C] Interactions & Density Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth C] Focus chain R [auth C]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.99 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-08-16

Deposition Author(s):

Funding Organization	Location	Grant Number
Other government	China	--

Revision History (Full details and data files)

Version 1.0: 2023-08-16
Type: Initial release
Version 1.1: 2024-11-20
Changes: Data collection, Structure summary
Version 1.2: 2025-07-02
Changes: Data collection
