7Y1U | pdb_00007y1u

Crystal structure of isocitrate dehydrogenase from Campylobacter corcagiensis

PDB DOI: https://doi.org/10.2210/pdb7Y1U/pdb

Classification: OXIDOREDUCTASE
Organism(s): Campylobacter corcagiensis
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2022-06-08 Released: 2023-07-05
Deposition Author(s): Bian, M.J., Cheng, Q.P., Wang, P., Zhu, G.P.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.259 (Depositor), 0.262 (DCC)
R-Value Work:
0.188 (Depositor), 0.198 (DCC)
R-Value Observed:
0.192 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of isocitrate dehydrogenase from Campylobacter corcagiensis

Bian, M.J., Cheng, Q.P., Wang, P., Zhu, G.P.

To be published.

Macromolecule Content

Total Structure Weight: 83.01 kDa
Atom Count: 5,975
Modeled Residue Count: 723
Deposited Residue Count: 723
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isocitrate dehydrogenase [NADP]	A	723	Campylobacter corcagiensis	Mutation(s): 0 Gene Names: IMC76_08370 EC: 1.1.1.42
UniProt
Find proteins for A0A7M1LFL5 (Campylobacter corcagiensis) Explore A0A7M1LFL5 Go to UniProtKB: A0A7M1LFL5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A7M1LFL5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAP (Subject of Investigation/LOI) Query on NAP Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE C₂₁ H₂₈ N₇ O₁₇ P₃ XJLXINKUBYWONI-NNYOXOHSSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
PG4 (Subject of Investigation/LOI) Query on PG4 Download:Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A]	I [auth A], J [auth A]	TETRAETHYLENE GLYCOL C₈ H₁₈ O₅ UWHCKJMYHZGTIT-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Interactions & Density Focus chain I [auth A] Focus chain J [auth A]
SO4 (Subject of Investigation/LOI) Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A], F [auth A], G [auth A], H [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A]
EDO (Subject of Investigation/LOI) Query on EDO Download:Ideal Coordinates CCD File SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A]	K [auth A], L [auth A], M [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Interactions & Density Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A]
MN (Subject of Investigation/LOI) Query on MN Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
