7XWJ | pdb_00007xwj

structure of patulin-detoxifying enzyme Y155F with NADPH


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.12 Å
  • R-Value Free:
    0.244 (Depositor), 0.247 (DCC)
  • R-Value Work:
    0.184 (Depositor), 0.192 (DCC)
  • R-Value Observed:
    0.187 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7XWJ

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Structure-based rational design of a short-chain dehydrogenase/reductase for improving activity toward mycotoxin patulin.

Dai, L.Li, H.Huang, J.W.Hu, Y.He, M.Yang, Y.Min, J.Guo, R.T.Chen, C.C.

(2022) Int J Biol Macromol 222: 421-428

  • DOI: https://doi.org/10.1016/j.ijbiomac.2022.09.121
  • Primary Citation Related Structures:
    7XWH, 7XWI, 7XWJ, 7XWK, 7XWL, 7XWM, 7XWN

  • PubMed Abstract:

    Patulin is a fatal mycotoxin that is widely detected in drinking water and fruit-derived products contaminated by diverse filamentous fungi. CgSDR from Candida guilliermondii represents the first NADPH-dependent short-chain dehydrogenase/reductase that catalyzes the reduction of patulin to the nontoxic E-ascladiol. To elucidate the catalytic mechanism of CgSDR, we solved its crystal structure in complex with cofactor and substrate. Structural analyses indicate that patulin is situated in a hydrophobic pocket adjacent to the cofactor, with the hemiacetal ring orienting toward the nicotinamide moiety of NADPH. In addition, we conducted structure-guided engineering to modify substrate-binding residue V187 and obtained variant V187F, V187K and V187W, whose catalytic activity was elevated by 3.9-, 2.2- and 1.7-fold, respectively. The crystal structures of CgSDR variants suggest that introducing additional aromatic stacking or hydrogen-bonding interactions to bind the lactone ring of patulin might account for the observed enhanced activity. These results illustrate the catalytic mechanism of SDR-mediated patulin detoxification for the first time and provide the upgraded variants that exhibit tremendous potentials in industrial applications.


  • Organizational Affiliation
    • State Key Laboratory of Biocatalysis and Enzyme Engineering, Hubei Hongshan Laboratory, Hubei Collaborative Innovation Center for Green Transformation of Bio-Resources, Hubei Key Laboratory of Industrial Biotechnology, School of Life Sciences, Hubei University, Wuhan, 430062, PR China.

Macromolecule Content

  • Total Structure Weight: 115.2 kDa
  • Atom Count: 7,772
  • Modeled Residue Count: 887
  • Deposited Residue Count: 1,044
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Short-chain dehydrogenase/reductase
A, B, C, D
261Meyerozyma guilliermondiiMutation(s): 1
Gene Names: SDR
EC: 1.1.1.1
UniProt
Find proteins for A0A888VSF1 (Meyerozyma guilliermondii)
Explore A0A888VSF1
Go to UniProtKB:  A0A888VSF1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A888VSF1
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.12 Å
  • R-Value Free:  0.244 (Depositor), 0.247 (DCC)
  • R-Value Work:  0.184 (Depositor), 0.192 (DCC)
  • R-Value Observed: 0.187 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.108α = 90
b = 65.116β = 107.07
c = 89.216γ = 90
Software Package:
Software NamePurpose
HKL-2000data scaling
REFMACrefinement
PDB_EXTRACTdata extraction
SAINTdata reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2022-10-26
    Type: Initial release
  • Version 1.1: 2023-11-29
    Changes: Data collection, Refinement description
  • Version 1.2: 2024-05-08
    Changes: Database references
