7WUA | pdb_00007wua

Crystal structures of FadD32 from Corynebacterium diphtheriae

PDB DOI: https://doi.org/10.2210/pdb7WUA/pdb

Classification: LIGASE
Organism(s): Corynebacterium diphtheriae
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2022-02-07 Released: 2022-08-10
Deposition Author(s): Liu, X.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.224 (Depositor), 0.224 (DCC)
R-Value Work:
0.185 (Depositor), 0.188 (DCC)
R-Value Observed:
0.187 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structures of FadD32 and pks13-ACP domain from Corynebacterium diphtheriae

Chen, R., Yuan, J., Shi, X., Tang, W.

(2022) Biochem Biophys Res Commun 590: 152-157

Macromolecule Content

Total Structure Weight: 265.69 kDa
Atom Count: 19,608
Modeled Residue Count: 2,283
Deposited Residue Count: 2,416
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Acyl-CoA synthase	A, B, C, D	604	Corynebacterium diphtheriae	Mutation(s): 0 Gene Names: CIP107532_02306
UniProt
Find proteins for Q6NES7 (Corynebacterium diphtheriae (strain ATCC 700971 / NCTC 13129 / Biotype gravis)) Explore Q6NES7 Go to UniProtKB: Q6NES7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q6NES7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ANP Query on ANP Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain H [auth B] SDF format, chain K [auth C] SDF format, chain M [auth D] MOL2 format, chain E [auth A] MOL2 format, chain H [auth B] MOL2 format, chain K [auth C] MOL2 format, chain M [auth D] mmCIF format, chain E [auth A] mmCIF format, chain H [auth B] mmCIF format, chain K [auth C] mmCIF format, chain M [auth D]	E [auth A], H [auth B], K [auth C], M [auth D]	PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER C₁₀ H₁₇ N₆ O₁₂ P₃ PVKSNHVPLWYQGJ-KQYNXXCUSA-N		Interactions Focus chain E [auth A] Focus chain H [auth B] Focus chain K [auth C] Focus chain M [auth D] Interactions & Density Focus chain E [auth A] Focus chain H [auth B] Focus chain K [auth C] Focus chain M [auth D]
MYR (Subject of Investigation/LOI) Query on MYR Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain I [auth B] SDF format, chain L [auth C] SDF format, chain N [auth D] MOL2 format, chain F [auth A] MOL2 format, chain I [auth B] MOL2 format, chain L [auth C] MOL2 format, chain N [auth D] mmCIF format, chain F [auth A] mmCIF format, chain I [auth B] mmCIF format, chain L [auth C] mmCIF format, chain N [auth D]	F [auth A], I [auth B], L [auth C], N [auth D]	MYRISTIC ACID C₁₄ H₂₈ O₂ TUNFSRHWOTWDNC-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain N [auth D] Interactions & Density Focus chain F [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain N [auth D]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain J [auth B] MOL2 format, chain G [auth A] MOL2 format, chain J [auth B] mmCIF format, chain G [auth A] mmCIF format, chain J [auth B]	G [auth A], J [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain J [auth B] Interactions & Density Focus chain G [auth A] Focus chain J [auth B]
