7WGX | pdb_00007wgx

SARS-CoV-2 spike glycoprotein trimer in closed state after treatment with Cathepsin L

PDB DOI: https://doi.org/10.2210/pdb7WGX/pdb
EM Map EMD-32491: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2021-12-29 Released: 2023-01-04
Deposition Author(s): Zhu, Y., Tai, L., Yin, G., Sun, F.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.50 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7WGX

This is version 1.1 of the entry. See complete history.

Literature

Novel cleavage sites identified in SARS-CoV-2 spike protein reveal mechanism for cathepsin L-facilitated viral infection and treatment strategies

Zhao, M.M., Zhu, Y., Zhang, L., Zhong, G., Tai, L., Liu, S., Yin, G., Lu, J., He, Q., Li, M.J., Zhao, R.X., Wang, H., Huang, W., Fan, C., Shuai, L., Wen, Z., Wang, C., He, X., Chen, Q., Liu, B., Xiong, X., Bu, Z., Wang, Y., Sun, F., Yang, J.K.

(2022) Cell Discov 8: 53

DOI: https://doi.org/10.1038/s41421-022-00419-w

Macromolecule Content

Total Structure Weight: 415.06 kDa
Atom Count: 25,629
Modeled Residue Count: 3,165
Deposited Residue Count: 3,612
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A, B, C	1,204	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0 Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2 Go to UniProtKB: P0DTC2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0DTC2
Glycosylation
Glycosylation Sites: 14	Glycosylation Focus chain A Focus chain B Focus chain C	Go to GlyGen: P0DTC2-1
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	D, E, F, G, H D, E, F, G, H, I, J, K, L, M, N, O, P, Q, R	2		N-Glycosylation	Interactions Focus chain D Focus chain E Focus chain F Focus chain G Focus chain H Focus chain I Focus chain J Focus chain K Focus chain L Focus chain M Focus chain N Focus chain O Focus chain P Focus chain Q Focus chain R Interactions & Density Focus chain D Focus chain E Focus chain F Focus chain G Focus chain H Focus chain I Focus chain J Focus chain K Focus chain L Focus chain M Focus chain N Focus chain O Focus chain P Focus chain Q Focus chain R
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
BLR Query on BLR Download:Ideal Coordinates CCD File SDF format, chain VA [auth C] SDF format, chain LA [auth B] SDF format, chain BA [auth A] MOL2 format, chain VA [auth C] MOL2 format, chain LA [auth B] MOL2 format, chain BA [auth A] mmCIF format, chain VA [auth C] mmCIF format, chain LA [auth B] mmCIF format, chain BA [auth A]	BA [auth A], LA [auth B], VA [auth C]	3-[5-[(Z)-(4-ethenyl-3-methyl-5-oxidanylidene-pyrrol-2-ylidene)methyl]-2-[[5-[(Z)-(3-ethenyl-4-methyl-5-oxidanylidene-pyrrol-2-ylidene)methyl]-3-(3-hydroxy-3-oxopropyl)-4-methyl-1H-pyrrol-2-yl]methyl]-4-methyl-1H-pyrrol-3-yl]propanoic acid C₃₃ H₃₆ N₄ O₆ BPYKTIZUTYGOLE-IFADSCNNSA-N		Interactions Focus chain BA [auth A] Focus chain LA [auth B] Focus chain VA [auth C] Interactions & Density Focus chain BA [auth A] Focus chain LA [auth B] Focus chain VA [auth C]
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain Z [auth A] SDF format, chain Y [auth A] SDF format, chain X [auth A] SDF format, chain W [auth A] SDF format, chain V [auth A] SDF format, chain UA [auth C] SDF format, chain U [auth A] SDF format, chain TA [auth C] SDF format, chain T [auth A] SDF format, chain SA [auth C] SDF format, chain S [auth A] SDF format, chain RA [auth C] SDF format, chain QA [auth C] SDF format, chain PA [auth C] SDF format, chain OA [auth C] SDF format, chain NA [auth C] SDF format, chain MA [auth C] SDF format, chain KA [auth B] SDF format, chain JA [auth B] SDF format, chain IA [auth B] SDF format, chain HA [auth B] SDF format, chain GA [auth B] SDF format, chain FA [auth B] SDF format, chain EA [auth B] SDF format, chain DA [auth B] SDF format, chain CA [auth B] SDF format, chain AA [auth A] MOL2 format, chain Z [auth A] MOL2 format, chain Y [auth A] MOL2 format, chain X [auth A] MOL2 format, chain W [auth A] MOL2 format, chain V [auth A] MOL2 format, chain UA [auth C] MOL2 format, chain U [auth A] MOL2 format, chain TA [auth C] MOL2 format, chain T [auth A] MOL2 format, chain SA [auth C] MOL2 format, chain S [auth A] MOL2 format, chain RA [auth C] MOL2 format, chain QA [auth C] MOL2 format, chain PA [auth C] MOL2 format, chain OA [auth C] MOL2 format, chain NA [auth C] MOL2 format, chain MA [auth C] MOL2 format, chain KA [auth B] MOL2 format, chain JA [auth B] MOL2 format, chain IA [auth B] MOL2 format, chain HA [auth B] MOL2 format, chain GA [auth B] MOL2 format, chain FA [auth B] MOL2 format, chain EA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain AA [auth A] mmCIF format, chain Z [auth A] mmCIF format, chain Y [auth A] mmCIF format, chain X [auth A] mmCIF format, chain W [auth A] mmCIF format, chain V [auth A] mmCIF format, chain UA [auth C] mmCIF format, chain U [auth A] mmCIF format, chain TA [auth C] mmCIF format, chain T [auth A] mmCIF format, chain SA [auth C] mmCIF format, chain S [auth A] mmCIF format, chain RA [auth C] mmCIF format, chain QA [auth C] mmCIF format, chain PA [auth C] mmCIF format, chain OA [auth C] mmCIF format, chain NA [auth C] mmCIF format, chain MA [auth C] mmCIF format, chain KA [auth B] mmCIF format, chain JA [auth B] mmCIF format, chain IA [auth B] mmCIF format, chain HA [auth B] mmCIF format, chain GA [auth B] mmCIF format, chain FA [auth B] mmCIF format, chain EA [auth B] mmCIF format, chain DA [auth B] mmCIF format, chain CA [auth B] mmCIF format, chain AA [auth A]	AA [auth A] CA [auth B] DA [auth B] EA [auth B] FA [auth B] AA [auth A], CA [auth B], DA [auth B], EA [auth B], FA [auth B], GA [auth B], HA [auth B], IA [auth B], JA [auth B], KA [auth B], MA [auth C], NA [auth C], OA [auth C], PA [auth C], QA [auth C], RA [auth C], S [auth A], SA [auth C], T [auth A], TA [auth C], U [auth A], UA [auth C], V [auth A], W [auth A], X [auth A], Y [auth A], Z [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AA [auth A] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain MA [auth C] Focus chain NA [auth C] Focus chain OA [auth C] Focus chain PA [auth C] Focus chain QA [auth C] Focus chain RA [auth C] Focus chain S [auth A] Focus chain SA [auth C] Focus chain T [auth A] Focus chain TA [auth C] Focus chain U [auth A] Focus chain UA [auth C] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A] Interactions & Density Focus chain AA [auth A] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain MA [auth C] Focus chain NA [auth C] Focus chain OA [auth C] Focus chain PA [auth C] Focus chain QA [auth C] Focus chain RA [auth C] Focus chain S [auth A] Focus chain SA [auth C] Focus chain T [auth A] Focus chain TA [auth C] Focus chain U [auth A] Focus chain UA [auth C] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.50 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-01-04

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2023-01-04
Type: Initial release
Version 1.1: 2024-11-20
Changes: Data collection, Structure summary
