7UYO | pdb_00007uyo

Crystal structure of B-form alien DNA 5'-CTTSSPBZPSZBBAAG in a host-guest complex with the N-terminal fragment of Moloney murine leukemia virus reverse transcriptase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free:
    0.257 (Depositor), 0.261 (DCC)
  • R-Value Work:
    0.227 (Depositor), 0.231 (DCC)
  • R-Value Observed:
    0.228 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7UYO

This is version 1.1 of the entry. See complete history

Literature

Crystal structures of 'ALternative Isoinformational ENgineered' DNA in B-form.

Shukla, M.S.Hoshika, S.Benner, S.A.Georgiadis, M.M.

(2023) Philos Trans R Soc Lond B Biol Sci 378: 20220028-20220028

  • DOI: https://doi.org/10.1098/rstb.2022.0028
  • Primary Citation Related Structures:
    7UYN, 7UYO, 7UYP

  • PubMed Abstract:

    The first structural model of duplex DNA reported in 1953 by Watson & Crick presented the double helix in B-form, the form that genomic DNA exists in much of the time. Thus, artificial DNA seeking to mimic the properties of natural DNA should also be able to adopt B-form. Using a host-guest system in which Moloney murine leukemia virus reverse transcriptase serves as the host and DNA as the guests, we determined high-resolution crystal structures of three complexes including 5'-CTT BPPBBSSZZS AAG, 5'-CTT SSPBZPSZBB AAG and 5'-CTT ZZPBSBSZPP AAG with 10 consecutive unnatural nucleobase pairs in B-form within self-complementary 16 bp duplex oligonucleotides. We refer to this ALternative Isoinformational ENgineered (ALIEN) genetic system containing two nucleobase pairs ( P:Z , pairing 2-amino-imidazo-[1,2- a ]-1,3,5-triazin-(8 H )-4-one with 6-amino-5-nitro-(1 H )-pyridin-2-one, and B:S , 6-amino-4-hydroxy-5-(1 H )-purin-2-one with 3-methyl-6-amino-pyrimidin-2-one) as ALIEN DNA. We characterized both position- and sequence-specific helical, nucleobase pair and dinucleotide step parameters of P:Z and B:S pairs in the context of B-form DNA. We conclude that ALIEN DNA exhibits structural features that vary with sequence. Further, Z can participate in alternative stacking modes within a similar sequence context as captured in two different structures. This finding suggests that ALIEN DNA may have a larger repertoire of B-form structures than natural DNA. This article is part of the theme issue 'Reactivity and mechanism in chemical and synthetic biology'.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biology, Indiana University School of Medicine, Indianapolis, IN 46202, USA.

Macromolecule Content

  • Total Structure Weight: 35.01 kDa
  • Atom Count: 2,469
  • Modeled Residue Count: 263
  • Deposited Residue Count: 282
  • Unique protein chains: 1
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
reverse transcriptase266Moloney murine leukemia virusMutation(s): 0
Gene Names: gag-pro-pol
UniProt
Find proteins for P03355 (Moloney murine leukemia virus (isolate Shinnick))
Explore P03355
Go to UniProtKB:  P03355
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03355
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*CP*TP*TP*(JSP)P*(JSP)P*(1WA)P*(IGU)P*(1W5))-3')8synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 3
MoleculeChains LengthOrganismImage
DNA (5'-D(P*(1WA)P*(JSP)P*(1W5)P*(IGU)P*(IGU)P*AP*AP*G)-3')C [auth G]8synthetic construct
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free:  0.257 (Depositor), 0.261 (DCC)
  • R-Value Work:  0.227 (Depositor), 0.231 (DCC)
  • R-Value Observed: 0.228 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 55.305α = 90
b = 145.928β = 90
c = 46.904γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, United States)United States193908

Revision History  (Full details and data files)

  • Version 1.0: 2023-05-10
    Type: Initial release
  • Version 1.1: 2023-10-25
    Changes: Data collection, Database references, Refinement description
