7UUR

The 1.67 Angstrom CryoEM structure of the [NiFe]-hydrogenase Huc from Mycobacterium smegmatis - catalytic dimer (Huc2S2L)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 1.67 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Structural basis for bacterial energy extraction from atmospheric hydrogen.

Grinter, R.Kropp, A.Venugopal, H.Senger, M.Badley, J.Cabotaje, P.R.Jia, R.Duan, Z.Huang, P.Stripp, S.T.Barlow, C.K.Belousoff, M.Shafaat, H.S.Cook, G.M.Schittenhelm, R.B.Vincent, K.A.Khalid, S.Berggren, G.Greening, C.

(2023) Nature 615: 541-547

  • DOI: https://doi.org/10.1038/s41586-023-05781-7
  • Primary Citation of Related Structures:
    7UTD, 7UUR, 7UUS, 8DQV

  • PubMed Abstract:

    Diverse aerobic bacteria use atmospheric H 2 as an energy source for growth and survival 1 . This globally significant process regulates the composition of the atmosphere, enhances soil biodiversity and drives primary production in extreme environments 2,3 . Atmospheric H 2 oxidation is attributed to uncharacterized members of the [NiFe] hydrogenase superfamily 4,5 . However, it remains unresolved how these enzymes overcome the extraordinary catalytic challenge of oxidizing picomolar levels of H 2 amid ambient levels of the catalytic poison O 2 and how the derived electrons are transferred to the respiratory chain 1 . Here we determined the cryo-electron microscopy structure of the Mycobacterium smegmatis hydrogenase Huc and investigated its mechanism. Huc is a highly efficient oxygen-insensitive enzyme that couples oxidation of atmospheric H 2 to the hydrogenation of the respiratory electron carrier menaquinone. Huc uses narrow hydrophobic gas channels to selectively bind atmospheric H 2 at the expense of O 2 , and 3 [3Fe-4S] clusters modulate the properties of the enzyme so that atmospheric H 2 oxidation is energetically feasible. The Huc catalytic subunits form an octameric 833 kDa complex around a membrane-associated stalk, which transports and reduces menaquinone 94 Å from the membrane. These findings provide a mechanistic basis for the biogeochemically and ecologically important process of atmospheric H 2 oxidation, uncover a mode of energy coupling dependent on long-range quinone transport, and pave the way for the development of catalysts that oxidize H 2 in ambient air.


  • Organizational Affiliation

    Department of Microbiology, Biomedicine Discovery Institute, Monash University, Clayton, Victoria, Australia. rhys.grinter@monash.edu.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Hydrogenase-2, large subunitA [auth C],
C [auth F]
513Mycolicibacterium smegmatis MC2 155Mutation(s): 0
EC: 1.12.99.6
UniProt
Find proteins for A0QUM7 (Mycolicibacterium smegmatis (strain ATCC 700084 / mc(2)155))
Explore A0QUM7
Go to UniProtKB:  A0QUM7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0QUM7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Hydrogenase-2, small subunitB [auth D],
D [auth G]
322Mycolicibacterium smegmatis MC2 155Mutation(s): 0
Gene Names: MSMEI_2206
EC: 1.12.99.6
UniProt
Find proteins for A0QUM6 (Mycolicibacterium smegmatis (strain ATCC 700084 / mc(2)155))
Explore A0QUM6
Go to UniProtKB:  A0QUM6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0QUM6
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
F3S (Subject of Investigation/LOI)
Query on F3S

Download Ideal Coordinates CCD File
J [auth D]
K [auth D]
L [auth D]
R [auth G]
S [auth G]
J [auth D],
K [auth D],
L [auth D],
R [auth G],
S [auth G],
T [auth G]
FE3-S4 CLUSTER
Fe3 S4
FCXHZBQOKRZXKS-UHFFFAOYSA-N
VK3 (Subject of Investigation/LOI)
Query on VK3

Download Ideal Coordinates CCD File
I [auth D],
Q [auth G]
MENADIONE
C11 H8 O2
MJVAVZPDRWSRRC-UHFFFAOYSA-N
FCO (Subject of Investigation/LOI)
Query on FCO

Download Ideal Coordinates CCD File
F [auth C],
N [auth F]
CARBONMONOXIDE-(DICYANO) IRON
C3 Fe N2 O
VBQUCMTXYFMTTE-UHFFFAOYSA-N
3NI (Subject of Investigation/LOI)
Query on 3NI

Download Ideal Coordinates CCD File
E [auth C],
M [auth F]
NICKEL (III) ION
Ni
JDRCAGKFDGHRNQ-UHFFFAOYSA-N
MG (Subject of Investigation/LOI)
Query on MG

Download Ideal Coordinates CCD File
H [auth C],
P [auth F]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
OH (Subject of Investigation/LOI)
Query on OH

Download Ideal Coordinates CCD File
G [auth C],
O [auth F]
HYDROXIDE ION
H O
XLYOFNOQVPJJNP-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 1.67 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.19.2
MODEL REFINEMENTCoot0.92
RECONSTRUCTIONcryoSPARC

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Australian Research Council (ARC)AustraliaDP200103074
National Health and Medical Research Council (NHMRC, Australia)AustraliaAPP1197376

Revision History  (Full details and data files)

  • Version 1.0: 2023-01-04
    Type: Initial release
  • Version 1.1: 2023-01-25
    Changes: Database references
  • Version 1.2: 2023-03-08
    Changes: Database references
  • Version 1.3: 2023-03-22
    Changes: Database references
  • Version 1.4: 2023-03-29
    Changes: Database references
  • Version 1.5: 2024-11-06
    Changes: Data collection, Structure summary
