7UPJ

HIV-1 PROTEASE/U101935 COMPLEX


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Work: 0.208

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Structure-based design of nonpeptidic HIV protease inhibitors: the sulfonamide-substituted cyclooctylpyramones.

Skulnick, H.I.Johnson, P.D.Aristoff, P.A.Morris, J.K.Lovasz, K.D.Howe, W.J.Watenpaugh, K.D.Janakiraman, M.N.Anderson, D.J.Reischer, R.J.Schwartz, T.M.Banitt, L.S.Tomich, P.K.Lynn, J.C.Horng, M.-M.Chong, K.-T.Hinshaw, R.R.Dolak, L.A.Seest, E.P.Schwende, F.J.Rush, B.D.Howard, G.M.Toth, L.N.Wilkinson, K.F.Kakuk, T.J.Johnson, C.W.Cole, S.L.Zaya, R.M.Zipp, G.L.Possert, P.L.Dalga, R.J.Zhong, W.-Z.Williams, M.G.Romines, K.R.

(1997) J Med Chem 40: 1149-1164

  • DOI: https://doi.org/10.1021/jm960441m
  • Primary Citation of Related Structures:
    1HPO, 7UPJ

  • PubMed Abstract:

    Recently, cyclooctylpyranone derivatives with m-carboxamide substituents (e.g. 2c) were identified as potent, nonpeptidic HIV protease inhibitors, but these compounds lacked significant antiviral activity in cell culture. Substitution of a sulfonamide group at the meta position, however, produces compounds with excellent HIV protease binding affinity and antiviral activity. Guided by an iterative structure-based drug design process, we have prepared and evaluated a number of these derivatives, which are readily available via a seven-step synthesis. A few of the most potent compounds were further evaluated for such characteristics as pharmacokinetics and toxicity in rats and dogs. From this work, the p-cyanophenyl sulfonamide derivative 35k emerged as a promising inhibitor, was selected for further development, and entered phase I clinical trials.


  • Organizational Affiliation

    Discovery Chemistry Research, Pharmacia and Upjohn, Kalamazoo, Michigan 49001, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
HIV-1 PROTEASE
A, B
99Human immunodeficiency virus 1Mutation(s): 0
EC: 3.4.23.16
UniProt
Find proteins for P03367 (Human immunodeficiency virus type 1 group M subtype B (isolate BRU/LAI))
Explore P03367
Go to UniProtKB:  P03367
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03367
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
INU
Query on INU

Download Ideal Coordinates CCD File
C [auth A]N-(3-CYCLOPROPYL(5,6,7,8,9,10-HEXAHYDRO-2-OXO-2H-CYCLOOCTA[B]PYRAN-3-YL)METHYL)PHENYLBENZENSULFONAMIDE
C27 H29 N O5 S
GDRNWAKVNIROCG-DEOSSOPVSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
INU PDBBind:  7UPJ Ki: 3.2 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Work: 0.208
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 60.374α = 90
b = 89.605β = 90
c = 47.341γ = 90
Software Package:
Software NamePurpose
MERLOTphasing
CEDARrefinement
XENGENdata reduction
XENGENdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1997-04-21
    Type: Initial release
  • Version 1.1: 2008-03-25
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2012-02-22
    Changes: Database references
  • Version 1.4: 2024-02-14
    Changes: Data collection, Database references, Derived calculations
  • Version 1.5: 2024-04-03
    Changes: Refinement description
