7UIU | pdb_00007uiu

N2 sub-domain of IF2 bound to the 30S subunit in the Pseudomonas aeruginosa 70S ribosome initiation complex (focused classification and refinement)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7UIU

This is version 1.2 of the entry. See complete history

Literature

Compact IF2 allows initiator tRNA accommodation into the P site and gates the ribosome to elongation.

Basu, R.S.Sherman, M.B.Gagnon, M.G.

(2022) Nat Commun 13: 3388-3388

  • DOI: https://doi.org/10.1038/s41467-022-31129-2
  • Primary Citation Related Structures:
    7UIU

  • PubMed Abstract:

    During translation initiation, initiation factor 2 (IF2) holds initiator transfer RNA (fMet-tRNA i fMet ) in a specific orientation in the peptidyl (P) site of the ribosome. Upon subunit joining IF2 hydrolyzes GTP and, concomitant with inorganic phosphate (P i ) release, changes conformation facilitating fMet-tRNA i fMet accommodation into the P site and transition of the 70 S ribosome initiation complex (70S-IC) to an elongation-competent ribosome. The mechanism by which IF2 separates from initiator tRNA at the end of translation initiation remains elusive. Here, we report cryo-electron microscopy (cryo-EM) structures of the 70S-IC from Pseudomonas aeruginosa bound to compact IF2-GDP and initiator tRNA. Relative to GTP-bound IF2, rotation of the switch 2 α-helix in the G-domain bound to GDP unlocks a cascade of large-domain movements in IF2 that propagate to the distal tRNA-binding domain C2. The C2-domain relocates 35 angstroms away from tRNA, explaining how IF2 makes way for fMet-tRNA i fMet accommodation into the P site. Our findings provide the basis by which IF2 gates the ribosome to the elongation phase.


  • Organizational Affiliation
    • Department of Microbiology and Immunology, University of Texas Medical Branch, Galveston, TX, 77555, USA.

Macromolecule Content

  • Total Structure Weight: 91.05 kDa
  • Atom Count: 607
  • Modeled Residue Count: 85
  • Deposited Residue Count: 840
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Translation initiation factor IF-2A [auth x]840Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: infBPA4744
UniProt
Find proteins for Q9HV55 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9HV55
Go to UniProtKB:  Q9HV55
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9HV55
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC3.1.0
MODEL REFINEMENTPHENIX1.19.2

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM136936
Robert A. Welch FoundationUnited StatesH-2032-20200401

Revision History  (Full details and data files)

  • Version 1.0: 2022-06-22
    Type: Initial release
  • Version 1.1: 2022-06-29
    Changes: Database references
  • Version 1.2: 2024-02-14
    Changes: Data collection
