7TMD | pdb_00007tmd

Crystal structure of Ornithine carbamoyltransferase from Klebsiella pneumoniae

PDB DOI: https://doi.org/10.2210/pdb7TMD/pdb

Classification: TRANSFERASE
Organism(s): Klebsiella pneumoniae subsp. pneumoniae HS11286
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2022-01-19 Released: 2022-02-02
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.35 Å
R-Value Free:
0.240 (Depositor), 0.234 (DCC)
R-Value Work:
0.171 (Depositor)
R-Value Observed:
0.175 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7TMD

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of Ornithine carbamoyltransferase from Klebsiella pneumoniae

Lovell, S., Liu, L., Battaile, K.P., Tillery, L., Shek, R., Craig, J.K., Barrett, L.K., Van Voorhis, W.C.

To be published.

Macromolecule Content

Total Structure Weight: 225.75 kDa
Atom Count: 15,546
Modeled Residue Count: 1,978
Deposited Residue Count: 2,052
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ornithine carbamoyltransferase	A, B, C, D, E A, B, C, D, E, F	342	Klebsiella pneumoniae subsp. pneumoniae HS11286	Mutation(s): 0 Gene Names: KPHS_05120 EC: 2.1.3.3
UniProt
Find proteins for A0A0H3GHJ1 (Klebsiella pneumoniae subsp. pneumoniae (strain HS11286)) Explore A0A0H3GHJ1 Go to UniProtKB: A0A0H3GHJ1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0H3GHJ1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
IOD Query on IOD Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
BR Query on BR Download:Ideal Coordinates CCD File SDF format, chain I [auth D] SDF format, chain H [auth A] MOL2 format, chain I [auth D] MOL2 format, chain H [auth A] mmCIF format, chain I [auth D] mmCIF format, chain H [auth A]	H [auth A], I [auth D]	BROMIDE ION Br CPELXLSAUQHCOX-UHFFFAOYSA-M		Interactions Focus chain H [auth A] Focus chain I [auth D] Interactions & Density Focus chain H [auth A] Focus chain I [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.35 Å
R-Value Free: 0.240 (Depositor), 0.234 (DCC)
R-Value Work: 0.171 (Depositor)
R-Value Observed: 0.175 (Depositor)

Diffraction Data:

Space Group: I 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 95.093	α = 90
b = 154.714	β = 91.04
c = 150.557	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
Aimless	data scaling
MOLREP	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-02-02

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700059C

Revision History (Full details and data files)

Version 1.0: 2022-02-02
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Refinement description
