7TJQ | pdb_00007tjq

SAN27-14 bound to a antigenic site V on prefusion-stabilized hMPV F


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.13 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7TJQ

This is version 1.2 of the entry. See complete history

Literature

Characterization of prefusion-F-specific antibodies elicited by natural infection with human metapneumovirus.

Rush, S.A.Brar, G.Hsieh, C.L.Chautard, E.Rainho-Tomko, J.N.Slade, C.D.Bricault, C.A.Kume, A.Kearns, J.Groppo, R.Mundle, S.T.Zhang, L.Casimiro, D.Fu, T.M.DiNapoli, J.M.McLellan, J.S.

(2022) Cell Rep 40: 111399-111399

  • DOI: https://doi.org/10.1016/j.celrep.2022.111399
  • Primary Citation Related Structures:
    7TJQ, 7TL0

  • PubMed Abstract:

    Human metapneumovirus (hMPV) is a major cause of acute respiratory infections in infants and older adults, for which no vaccines or therapeutics are available. The viral fusion (F) glycoprotein is required for entry and is the primary target of neutralizing antibodies; however, little is known about the humoral immune response generated from natural infection. Here, using prefusion-stabilized F proteins to interrogate memory B cells from two older adults, we obtain over 700 paired non-IgM antibody sequences representing 563 clonotypes, indicative of a highly polyclonal response. Characterization of 136 monoclonal antibodies reveals broad recognition of the protein surface, with potently neutralizing antibodies targeting each antigenic site. Cryo-EM studies further reveal two non-canonical sites and the molecular basis for recognition of the apex of hMPV F by two prefusion-specific neutralizing antibodies. Collectively, these results provide insight into the humoral response to hMPV infection in older adults and will help guide vaccine development.


  • Organizational Affiliation
    • Department of Molecular Biosciences, The University of Texas at Austin, Austin, TX 78712, USA.

Macromolecule Content

  • Total Structure Weight: 403.42 kDa
  • Atom Count: 20,538
  • Modeled Residue Count: 2,679
  • Deposited Residue Count: 3,702
  • Unique protein chains: 5

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
SAN27-14 Fab heavy chain
A, D, H
124Homo sapiensMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
SAN27-14 Fab light chain
B, E, L
115Homo sapiensMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Fusion glycoprotein F0
C, F, G
551human metapneumovirusMutation(s): 14
UniProt
Find proteins for Q8B9P0 (human metapneumovirus)
Explore Q8B9P0
Go to UniProtKB:  Q8B9P0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8B9P0
Glycosylation
Glycosylation Sites: 1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
MPE8 Fab heavy chain
I, J, N
230Homo sapiensMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
MPE8 Fab light chain
K, M, O
214Homo sapiensMutation(s): 0

Oligosaccharides

Help
Entity ID: 6
MoleculeChains Length2D Diagram GlycosylationD Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
P, Q, R, S, T
P, Q, R, S, T, U
2N-Glycosylation
Glycosylation Resources
GlyTouCan: G42666HT
GlyCosmos: G42666HT
GlyGen: G42666HT

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.13 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Welch FoundationUnited StatesF-0003-19620604

Revision History  (Full details and data files)

  • Version 1.0: 2022-09-14
    Type: Initial release
  • Version 1.1: 2022-11-23
    Changes: Database references
  • Version 1.2: 2024-10-23
    Changes: Data collection, Structure summary
