7SKJ | pdb_00007skj

Crystal structure of chloroplast triosephosphate isomerase from Cuscuta australis

PDB DOI: https://doi.org/10.2210/pdb7SKJ/pdb

Classification: ISOMERASE
Organism(s): Cuscuta australis
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-10-20 Released: 2022-10-26
Deposition Author(s): Jones, G., Vickers, C., Patrick, W.
Funding Organization(s): Royal Society of New Zealand

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.235 (Depositor), 0.235 (DCC)
R-Value Work:
0.185 (Depositor), 0.187 (DCC)
R-Value Observed:
0.187 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7SKJ

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of chloroplast triosephosphate isomerase from Cuscuta australis

Jones, G., Vickers, C., Patrick, W.

To be published.

Macromolecule Content

Total Structure Weight: 118.39 kDa
Atom Count: 7,963
Modeled Residue Count: 968
Deposited Residue Count: 1,100
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Triosephosphate isomerase	A, B, C, D	275	Cuscuta australis	Mutation(s): 0 Gene Names: DM860_005218
UniProt
Find proteins for A0A328DYS8 (Cuscuta australis) Explore A0A328DYS8 Go to UniProtKB: A0A328DYS8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A328DYS8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ACT (Subject of Investigation/LOI) Query on ACT Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth C] MOL2 format, chain E [auth A] MOL2 format, chain F [auth C] mmCIF format, chain E [auth A] mmCIF format, chain F [auth C]	E [auth A], F [auth C]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain F [auth C] Interactions & Density Focus chain E [auth A] Focus chain F [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.235 (Depositor), 0.235 (DCC)
R-Value Work: 0.185 (Depositor), 0.187 (DCC)
R-Value Observed: 0.187 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.949	α = 90
b = 82.118	β = 90
c = 154.246	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
MOSFLM	data reduction
Aimless	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-10-26

Deposition Author(s):

Funding Organization	Location	Grant Number
Royal Society of New Zealand	New Zealand	--

Revision History (Full details and data files)

Version 1.0: 2022-10-26
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Refinement description
