7SBB | pdb_00007sbb

Structure of type I-D Cascade bound to a ssRNA target


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7SBB

This is version 1.1 of the entry. See complete history

Literature

Structural rearrangements allow nucleic acid discrimination by type I-D Cascade.

Schwartz, E.A.McBride, T.M.Bravo, J.P.K.Wrapp, D.Fineran, P.C.Fagerlund, R.D.Taylor, D.W.

(2022) Nat Commun 13: 2829-2829

  • DOI: https://doi.org/10.1038/s41467-022-30402-8
  • Primary Citation Related Structures:
    7SBA, 7SBB

  • PubMed Abstract:

    CRISPR-Cas systems are adaptive immune systems that protect prokaryotes from foreign nucleic acids, such as bacteriophages. Two of the most prevalent CRISPR-Cas systems include type I and type III. Interestingly, the type I-D interference proteins contain characteristic features of both type I and type III systems. Here, we present the structures of type I-D Cascade bound to both a double-stranded (ds)DNA and a single-stranded (ss)RNA target at 2.9 and 3.1 Å, respectively. We show that type I-D Cascade is capable of specifically binding ssRNA and reveal how PAM recognition of dsDNA targets initiates long-range structural rearrangements that likely primes Cas10d for Cas3' binding and subsequent non-target strand DNA cleavage. These structures allow us to model how binding of the anti-CRISPR protein AcrID1 likely blocks target dsDNA binding via competitive inhibition of the DNA substrate engagement with the Cas10d active site. This work elucidates the unique mechanisms used by type I-D Cascade for discrimination of single-stranded and double stranded targets. Thus, our data supports a model for the hybrid nature of this complex with features of type III and type I systems.


  • Organizational Affiliation
    • Department of Molecular Biosciences, University of Texas at Austin, Austin, TX, 78712-1597, USA.

Macromolecule Content

  • Total Structure Weight: 455.15 kDa
  • Atom Count: 28,938
  • Modeled Residue Count: 3,511
  • Deposited Residue Count: 3,900
  • Unique protein chains: 4
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Cas7d
A, B, C, D, E
A, B, C, D, E, F, G
329Synechocystis sp. PCC 6803Mutation(s): 0
Gene Names: slr7012
UniProt
Find proteins for Q6ZEI6 (Synechocystis sp. (strain ATCC 27184 / PCC 6803 / Kazusa))
Explore Q6ZEI6
Go to UniProtKB:  Q6ZEI6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6ZEI6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Cas5d254Synechocystis sp. PCC 6803Mutation(s): 0
Gene Names: slr7013
UniProt
Find proteins for Q6ZEI5 (Synechocystis sp. (strain ATCC 27184 / PCC 6803 / Kazusa))
Explore Q6ZEI5
Go to UniProtKB:  Q6ZEI5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6ZEI5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Cas10d975Synechocystis sp. PCC 6803Mutation(s): 0
Gene Names: slr7011
UniProt
Find proteins for Q6ZEI7 (Synechocystis sp. (strain ATCC 27184 / PCC 6803 / Kazusa))
Explore Q6ZEI7
Go to UniProtKB:  Q6ZEI7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6ZEI7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Cas11d
J, K
146Synechocystis sp. PCC 6803Mutation(s): 0
Gene Names: slr7011
UniProt
Find proteins for Q6ZEI7 (Synechocystis sp. (strain ATCC 27184 / PCC 6803 / Kazusa))
Explore Q6ZEI7
Go to UniProtKB:  Q6ZEI7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6ZEI7
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 5
MoleculeChains LengthOrganismImage
ssRNA targetL [auth X]33synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 6
MoleculeChains LengthOrganismImage
crRNAM [auth Z]43Synechocystis sp. PCC 6803
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC2
MODEL REFINEMENTISOLDE

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Welch FoundationUnited StatesF-1938

Revision History  (Full details and data files)

  • Version 1.0: 2022-06-08
    Type: Initial release
  • Version 1.1: 2024-06-05
    Changes: Data collection
