7R4U

Apoform of FtrA/P19 from Rubrivivax gelatinosus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.23 Å
  • R-Value Free: 0.186
  • R-Value Work: 0.170
  • R-Value Observed: 0.171

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

New insights into the mechanism of iron transport through the bacterial Ftr system present in pathogens.

Steunou, A.S.Vigouroux, A.Aumont-Nicaise, M.Plancqueel, S.Boussac, A.Ouchane, S.Morera, S.

(2022) FEBS J 289: 6286-6307

  • DOI: https://doi.org/10.1111/febs.16476
  • Primary Citation of Related Structures:
    7R3P, 7R3S, 7R4U, 7R4V, 7R4Z, 7R5E, 7R5G, 7R5P

  • PubMed Abstract:

    Iron is an essential nutrient in bacteria. Its ferrous form, mostly present in low oxygen and acidic pH environments, can be imported using the specific Ftr-type transport system, which encompasses the conserved FtrABCD system found in pathogenic bacteria such as Bordetella, Brucella and Burkholderia. The nonpathogenicity and versatile metabolism of Rubrivivax gelatinosus make it an ideal model to study the FtrABCD system. Here, we report a new aspect of its regulation and the role of the periplasmic proteins FtrA and FtrB using in vivo and in vitro approaches. We investigated the metal binding mode and redox state of copper and iron to FtrA by crystallography and biophysical methods. An 'as isolated' FtrA protein from the bacterial periplasm contained a copper ion (Cu + ) identified by electron paramagnetic resonance (EPR). Copper is coordinated by four conserved side chains (His and Met) in the primary metal site. Structural analysis of R. gelatinosus FtrA and FtrA homologues revealed that copper binding induces a rearrangement of the His95 imidazole ring, releasing thereafter space, as well as both Asp45 and Asp92 side chains, for iron binding in the secondary metal site. EPR highlighted that FtrA can oxidize the bound ferrous ion into the ferric form by reducing the bound Cu 2+ into Cu + , both metal sites being separated by 7 Å. Finally, we showed that FtrB binds iron and not copper. These results provide new insights into the mechanism of ferrous iron utilization by the conserved FtrABCD iron transporter for which we propose a new functional model.


  • Organizational Affiliation

    Université Paris-Saclay, CEA, CNRS, Institute for Integrative Biology of the Cell (I2BC), Gif-sur-Yvette, France.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
FtrA-P19
A, B
163Rubrivivax gelatinosusMutation(s): 0
Gene Names: EV684_12117
UniProt
Find proteins for A0A4R2M5S2 (Rubrivivax gelatinosus)
Explore A0A4R2M5S2
Go to UniProtKB:  A0A4R2M5S2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A4R2M5S2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
C [auth A],
D [auth A],
J [auth B],
K [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
I [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
NA
Query on NA

Download Ideal Coordinates CCD File
E [auth A],
F [auth A],
G [auth A],
H [auth A],
L [auth B]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.23 Å
  • R-Value Free: 0.186
  • R-Value Work: 0.170
  • R-Value Observed: 0.171
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 59.34α = 90
b = 79.97β = 90
c = 82.88γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
PHASERphasing
BUSTERrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Centre National de la Recherche Scientifique (CNRS)France--

Revision History  (Full details and data files)

  • Version 1.0: 2022-05-18
    Type: Initial release
  • Version 1.1: 2022-10-26
    Changes: Database references
  • Version 1.2: 2024-01-31
    Changes: Data collection, Refinement description
