7QSE

human Carbonic Anhydrase II in complex with N-(2-aminophenyl)-4-((2-oxo-2-((4-sulfamoylbenzyl)amino)ethyl)amino)benzamide

• PDB DOI: https://doi.org/10.2210/pdb7QSE/pdb

• Classification: LYASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2022-01-13 Released: 2023-01-25
• Deposition Author(s): Angeli, A., Ferraroni, M.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.43 Å
• R-Value Free: 0.164
• R-Value Work: 0.147

Starting Model: experimental

Literature

human Carbonic Anhydrase II in complex with N-(2-aminophenyl)-4-((2-oxo-2-((4-sulfamoylbenzyl)amino)ethyl)amino)benzamide

Angeli, A., Ferraroni, M.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 29.9 kDa
• Atom Count: 2,332
• Modelled Residue Count: 258
• Deposited Residue Count: 260
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carbonic anhydrase 2	A [auth AAA]	260	Homo sapiens	Mutation(s): 0  Gene Names: CA2 EC: 4.2.1.1 (PDB Primary Data), 4.2.1.69 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P00918 (Homo sapiens) Explore P00918  Go to UniProtKB:  P00918
PHAROS:  P00918 GTEx:  ENSG00000104267

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
EUM (Subject of Investigation/LOI)	C [auth AAA]	~{N}-(2-aminophenyl)-4-[[2-oxidanylidene-2-[(4-sulfamoylphenyl)methylamino]ethyl]amino]benzamide C22 H23 N5 O4 S KRLAWRCHRJIBIQ-UHFFFAOYSA-N
GOL (Subject of Investigation/LOI)	B [auth AAA]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
ZN (Subject of Investigation/LOI)	D [auth AAA]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.43 Å
• R-Value Free: 0.164
• R-Value Work: 0.147
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.317	α = 90
b = 41.243	β = 104.346
c = 72.085	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
REFMAC	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-01-25
Deposition Author(s): Angeli, A., Ferraroni, M.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2023-01-25
  Type: Initial release

• Version 1.1: 2023-08-23
  Changes: Data collection, Database references, Structure summary
• Version 1.2: 2024-01-31
  Changes: Refinement description
