7QGJ | pdb_00007qgj

Apo structure of BIR2 Domain of BIRC2

PDB DOI: https://doi.org/10.2210/pdb7QGJ/pdb

Classification: LIGASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2021-12-08 Released: 2022-02-09
Deposition Author(s): Kraemer, A., Farges, F., Schwalm, M.P., Saxena, K., Preuss, F., Knapp, S., Structural Genomics Consortium (SGC)
Funding Organization(s): European Commission

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free:
0.155 (Depositor), 0.170 (DCC)
R-Value Work:
0.142 (Depositor), 0.150 (DCC)
R-Value Observed:
0.143 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7QGJ

This is version 1.1 of the entry. See complete history.

Literature

Apo structure BIR2 Domain of BIRC2

Kraemer, A., Farges, F., Schwalm, M.P., Saxena, K., Knapp, S., Structural Genomics Consortium (SGC)

To be published.

Macromolecule Content

Total Structure Weight: 19.74 kDa
Atom Count: 1,477
Modeled Residue Count: 157
Deposited Residue Count: 166
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Baculoviral IAP repeat-containing protein 2	A, B	83	Homo sapiens	Mutation(s): 0 Gene Names: BIRC2, API1, MIHB, RNF48 EC: 2.3.2.27
UniProt & NIH Common Fund Data Resources
Find proteins for Q13490 (Homo sapiens) Explore Q13490 Go to UniProtKB: Q13490
PHAROS: Q13490 GTEx: ENSG00000110330
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q13490
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain J [auth B] MOL2 format, chain C [auth A] MOL2 format, chain J [auth B] mmCIF format, chain C [auth A] mmCIF format, chain J [auth B]	C [auth A], J [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain J [auth B] Interactions & Density Focus chain C [auth A] Focus chain J [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain M [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B]	D [auth A] E [auth A] F [auth A] G [auth A] H [auth A] D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], K [auth B], L [auth B], M [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free: 0.155 (Depositor), 0.170 (DCC)
R-Value Work: 0.142 (Depositor), 0.150 (DCC)
R-Value Observed: 0.143 (Depositor)

Space Group: H 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 87.241	α = 90
b = 87.241	β = 90
c = 59.625	γ = 120

Software Package:

Software Name	Purpose
XDS	data reduction
Aimless	data scaling
MOLREP	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-02-09

Deposition Author(s):

Structural Genomics Consortium (SGC)

Funding Organization	Location	Grant Number
European Commission	European Union	875510

Revision History (Full details and data files)

Version 1.0: 2022-02-09
Type: Initial release
Version 1.1: 2024-05-01
Changes: Data collection, Refinement description
