7P49

HLA-E*01:03 in complex with Mtb14


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.237
  • R-Value Observed: 0.239

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Primary and secondary functions of HLA-E are determined by stability and conformation of the peptide-bound complexes.

Walters, L.C.Rozbesky, D.Harlos, K.Quastel, M.Sun, H.Springer, S.Rambo, R.P.Mohammed, F.Jones, E.Y.McMichael, A.J.Gillespie, G.M.

(2022) Cell Rep 39: 110959-110959

  • DOI: https://doi.org/10.1016/j.celrep.2022.110959
  • Primary Citation of Related Structures:
    7P49, 7P4B

  • PubMed Abstract:

    MHC-E regulates NK cells by displaying MHC class Ia signal peptides (VL9) to NKG2A:CD94 receptors. MHC-E can also present sequence-diverse, lower-affinity, pathogen-derived peptides to T cell receptors (TCRs) on CD8 + T cells. To understand these affinity differences, human MHC-E (HLA-E)-VL9 versus pathogen-derived peptide structures are compared. Small-angle X-ray scatter (SAXS) measures biophysical parameters in solution, allowing comparison with crystal structures. For HLA-E-VL9, there is concordance between SAXS and crystal parameters. In contrast, HLA-E-bound pathogen-derived peptides produce larger SAXS dimensions that reduce to their crystallographic dimensions only when excess peptide is supplied. Further crystallographic analysis demonstrates three amino acids, exclusive to MHC-E, that not only position VL9 close to the α2 helix, but also allow non-VL9 peptide binding with re-configuration of a key TCR-interacting α2 region. Thus, non-VL9-bound peptides introduce an alternative peptide-binding motif and surface recognition landscape, providing a likely basis for VL9- and non-VL9-HLA-E immune discrimination.


  • Organizational Affiliation

    Nuffield Department of Medicine Research Building, Nuffield Department of Medicine, University of Oxford, Roosevelt Drive, Oxford OX3 7FZ, UK.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
HLA class I histocompatibility antigen, alpha chain E
A, C, E, G
276Homo sapiensMutation(s): 0
Gene Names: HLA-EHLA-6.2HLAE
UniProt & NIH Common Fund Data Resources
Find proteins for P13747 (Homo sapiens)
Explore P13747
Go to UniProtKB:  P13747
PHAROS:  P13747
GTEx:  ENSG00000204592
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13747
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Beta-2-microglobulin
B, D, F, H
100Homo sapiensMutation(s): 0
Gene Names: B2MCDABP0092HDCMA22P
UniProt & NIH Common Fund Data Resources
Find proteins for P61769 (Homo sapiens)
Explore P61769
Go to UniProtKB:  P61769
PHAROS:  P61769
GTEx:  ENSG00000166710
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP61769
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Phenolphthiocerol/phthiocerol polyketide synthase subunit BI [auth P],
J [auth Q],
K [auth R],
L [auth Z]
9Mycobacterium tuberculosis H37RvMutation(s): 0
Gene Names: ppsBRv2932MTCY338.21MTV011.01
EC: 2.3.1.292
UniProt
Find proteins for P9WQE5 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WQE5
Go to UniProtKB:  P9WQE5
Entity Groups
UniProt GroupP9WQE5
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
AA [auth C]
BA [auth C]
CA [auth C]
DA [auth C]
GA [auth D]
AA [auth C],
BA [auth C],
CA [auth C],
DA [auth C],
GA [auth D],
HA [auth D],
KA [auth E],
LA [auth E],
MA [auth F],
NA [auth F],
O [auth A],
OA [auth F],
P [auth A],
Q [auth A],
R [auth A],
RA [auth G],
S [auth A],
SA [auth G],
TA [auth H],
U [auth B],
UA [auth H],
V [auth B],
VA [auth H],
WA [auth P],
XA [auth Q],
YA [auth R],
ZA [auth Z]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
EA [auth D]
FA [auth D]
IA [auth E]
M [auth A]
N [auth A]
EA [auth D],
FA [auth D],
IA [auth E],
M [auth A],
N [auth A],
PA [auth G],
T [auth B],
W [auth B],
X [auth C],
Y [auth C],
Z [auth C]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
JA [auth E],
QA [auth G]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.237
  • R-Value Observed: 0.239
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 245.15α = 90
b = 47.926β = 117.452
c = 152.445γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PHENIXrefinement
xia2data reduction
xia2data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Bill & Melinda Gates Foundation--

Revision History  (Full details and data files)

  • Version 1.0: 2022-06-22
    Type: Initial release
  • Version 1.1: 2022-08-03
    Changes: Database references
  • Version 1.2: 2024-01-31
    Changes: Data collection, Refinement description
  • Version 1.3: 2024-10-16
    Changes: Structure summary
