7P1Y | pdb_00007p1y

A small alarmone hydrolase TdActApo2 mutant - T78N

PDB DOI: https://doi.org/10.2210/pdb7P1Y/pdb

Classification: HYDROLASE
Organism(s): Treponema denticola ATCC 35405
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2021-07-02 Released: 2022-07-13
Deposition Author(s): Jin, Y., Roth, C., Rizkallah, P.
Funding Organization(s): Wellcome Trust

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.38 Å
R-Value Free:
0.227 (Depositor), 0.229 (DCC)
R-Value Work:
0.191 (Depositor), 0.193 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7P1Y

This is version 1.2 of the entry. See complete history.

Literature

A small alarmone hydrolase TdActApo2 mutant - T78N

Jin, Y., Roth, C., Rizkallah, P.

To be published.

Macromolecule Content

Total Structure Weight: 106.62 kDa
Atom Count: 5,609
Modeled Residue Count: 688
Deposited Residue Count: 928
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
HD domain-containing protein	A [auth BBB], B [auth DDD], C [auth CCC], D [auth AAA]	232	Treponema denticola ATCC 35405	Mutation(s): 1 Gene Names: TDE_1690
UniProt
Find proteins for Q73M21 (Treponema denticola (strain ATCC 35405 / DSM 14222 / CIP 103919 / JCM 8153 / KCTC 15104)) Explore Q73M21 Go to UniProtKB: Q73M21
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q73M21
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MN (Subject of Investigation/LOI) Query on MN Download:Ideal Coordinates CCD File SDF format, chain J [auth AAA] SDF format, chain H [auth CCC] SDF format, chain F [auth DDD] SDF format, chain E [auth BBB] MOL2 format, chain J [auth AAA] MOL2 format, chain H [auth CCC] MOL2 format, chain F [auth DDD] MOL2 format, chain E [auth BBB] mmCIF format, chain J [auth AAA] mmCIF format, chain H [auth CCC] mmCIF format, chain F [auth DDD] mmCIF format, chain E [auth BBB]	E [auth BBB], F [auth DDD], H [auth CCC], J [auth AAA]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N		Interactions Focus chain E [auth BBB] Focus chain F [auth DDD] Focus chain H [auth CCC] Focus chain J [auth AAA] Interactions & Density Focus chain E [auth BBB] Focus chain F [auth DDD] Focus chain H [auth CCC] Focus chain J [auth AAA]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain I [auth AAA] SDF format, chain G [auth CCC] MOL2 format, chain I [auth AAA] MOL2 format, chain G [auth CCC] mmCIF format, chain I [auth AAA] mmCIF format, chain G [auth CCC]	G [auth CCC], I [auth AAA]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain G [auth CCC] Focus chain I [auth AAA] Interactions & Density Focus chain G [auth CCC] Focus chain I [auth AAA]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.38 Å
R-Value Free: 0.227 (Depositor), 0.229 (DCC)
R-Value Work: 0.191 (Depositor), 0.193 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.286	α = 90
b = 69.189	β = 93.015
c = 132.07	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
xia2	data reduction
xia2	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-07-13

Deposition Author(s):

Funding Organization	Location	Grant Number
Wellcome Trust	United Kingdom	209057/Z/17/Z

Revision History (Full details and data files)

Version 1.0: 2022-07-13
Type: Initial release
Version 1.1: 2024-01-31
Changes: Data collection, Refinement description
Version 1.2: 2024-11-13
Changes: Structure summary
