7OKW | pdb_00007okw

1.62A X-ray crystal structure of the conserved C-terminal (CCT) of human OSR1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.62 Å
  • R-Value Free:
    0.216 (Depositor), 0.218 (DCC)
  • R-Value Work:
    0.184 (Depositor), 0.188 (DCC)
  • R-Value Observed:
    0.186 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7OKW

This is version 1.3 of the entry. See complete history

Literature

Structures of the Human SPAK and OSR1 Conserved C-Terminal (CCT) Domains.

Elvers, K.T.Lipka-Lloyd, M.Trueman, R.C.Bax, B.D.Mehellou, Y.

(2022) Chembiochem 23: e202100441-e202100441

  • DOI: https://doi.org/10.1002/cbic.202100441
  • Primary Citation Related Structures:
    7O86, 7OKW

  • PubMed Abstract:

    STE20/SPS1-related proline/alanine-rich kinase (SPAK) and oxidative stress responsive 1 (OSR1) kinase are two serine/threonine protein kinases that regulate the function of ion co-transporters through phosphorylation. The highly conserved C-terminal (CCT) domains of SPAK and OSR1 bind to RFx[V/I] peptide sequences from their upstream 'With No Lysine Kinases (WNKs), facilitating their activation via phosphorylation. Thus, the inhibition of SPAK and OSR1 binding, via their CCT domains, to WNK kinases is a plausible strategy for inhibiting SPAK and OSR1 kinases. To facilitate structure-guided drug design of such inhibitors, we expressed and purified human SPAK and OSR1 CCT domains and solved their crystal structures. Interestingly, these crystal structures show a highly conserved primary pocket adjacent to a flexible secondary pocket. We also employed a biophysical strategy and determined the affinity of SPAK and OSR1 CCT domains to short peptides derived from WNK4 and NKCC1. Together, this work provides a platform that facilitates the design of CCT domain specific small molecule binders that inhibit SPAK- and OSR1-activation by WNK kinases, and these could be useful in treating hypertension and ischemic stroke.


  • Organizational Affiliation
    • Cardiff School of Pharmacy and Pharmaceutical Sciences, Cardiff University, Cardiff, CF10 3NB, UK.

Macromolecule Content

  • Total Structure Weight: 22.96 kDa
  • Atom Count: 1,733
  • Modeled Residue Count: 194
  • Deposited Residue Count: 212
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Serine/threonine-protein kinase OSR1
A, B
106Homo sapiensMutation(s): 0
Gene Names: OXSR1KIAA1101OSR1
EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for O95747 (Homo sapiens)
Explore O95747
Go to UniProtKB:  O95747
PHAROS:  O95747
GTEx:  ENSG00000172939
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO95747
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MPD

Query on MPD



Download:Ideal Coordinates CCD File
C [auth A],
G [auth B]
(4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
CA

Query on CA



Download:Ideal Coordinates CCD File
D [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
E [auth A],
H [auth B]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
NA

Query on NA



Download:Ideal Coordinates CCD File
F [auth A],
I [auth B]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.62 Å
  • R-Value Free:  0.216 (Depositor), 0.218 (DCC)
  • R-Value Work:  0.184 (Depositor), 0.188 (DCC)
  • R-Value Observed: 0.186 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.168α = 90
b = 49.424β = 99.442
c = 56.439γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PHENIXrefinement
autoPROCdata reduction
STARANISOdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Medical Research Council (MRC, United Kingdom)United Kingdom518455

Revision History  (Full details and data files)

  • Version 1.0: 2021-09-22
    Type: Initial release
  • Version 1.1: 2021-11-17
    Changes: Data collection, Database references
  • Version 1.2: 2022-01-19
    Changes: Data collection, Database references
  • Version 1.3: 2024-01-31
    Changes: Data collection, Refinement description
