7N9J | pdb_00007n9j

Crystal structure of H2DB in complex with HSF2 melanoma neoantigen

PDB DOI: https://doi.org/10.2210/pdb7N9J/pdb

Classification: IMMUNE SYSTEM
Organism(s): Mus musculus, Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-06-18 Released: 2022-06-22
Deposition Author(s): Patskovsky, Y., Finnigan, J., Patskovska, L., Newman, J., Bhardwaj, N., Krogsgaard, M.
Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.74 Å
R-Value Free:
0.213 (Depositor), 0.220 (DCC)
R-Value Work:
0.165 (Depositor), 0.176 (DCC)
R-Value Observed:
0.167 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7N9J

This is version 1.2 of the entry. See complete history.

Literature

Structure of the complex between H2DB and melanoma HSF2 neoantigen YGFRNVVHI

Patskovsky, Y., Finnigan, J., Patskovska, L., Newman, J., Bhardwaj, N., Krogsgaard, M.

To be published.

Macromolecule Content

Total Structure Weight: 45.59 kDa
Atom Count: 3,657
Modeled Residue Count: 385
Deposited Residue Count: 390
Unique protein chains: 3

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
H-2 class I histocompatibility antigen, D-B alpha chain	A	281	Mus musculus	Mutation(s): 0 Gene Names: H2-D1
UniProt
Find proteins for P01899 (Mus musculus) Explore P01899 Go to UniProtKB: P01899
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P01899
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Heat shock factor protein 2	B [auth C]	9	Mus musculus	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P38533 (Mus musculus) Explore P38533 Go to UniProtKB: P38533
IMPC: MGI:96239
Entity Groups
UniProt Group	P38533
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-2-microglobulin	C [auth B]	100	Homo sapiens	Mutation(s): 0 Gene Names: B2M, CDABP0092, HDCMA22P
UniProt & NIH Common Fund Data Resources
Find proteins for P61769 (Homo sapiens) Explore P61769 Go to UniProtKB: P61769
PHAROS: P61769 GTEx: ENSG00000166710
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P61769
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.74 Å
R-Value Free: 0.213 (Depositor), 0.220 (DCC)
R-Value Work: 0.165 (Depositor), 0.176 (DCC)
R-Value Observed: 0.167 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 104.416	α = 90
b = 56.959	β = 94.84
c = 72.765	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-06-22

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	CA243486

Revision History (Full details and data files)

Version 1.0: 2022-06-22
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Refinement description
Version 1.2: 2024-10-09
Changes: Structure summary
