7MR2

Cryo-EM structure of RecBCD with undocked RecBNuc and flexible RecD


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.30 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Heterogeneity in E. coli RecBCD Helicase-DNA Binding and Base Pair Melting.

Hao, L.Zhang, R.Lohman, T.M.

(2021) J Mol Biol 433: 167147-167147

  • DOI: https://doi.org/10.1016/j.jmb.2021.167147
  • Primary Citation of Related Structures:
    7MR0, 7MR1, 7MR2, 7MR3, 7MR4

  • PubMed Abstract:

    E. coli RecBCD, a helicase/nuclease involved in double stranded (ds) DNA break repair, binds to a dsDNA end and melts out several DNA base pairs (bp) using only its binding free energy. We examined RecBCD-DNA initiation complexes using thermodynamic and structural approaches. Measurements of enthalpy changes for RecBCD binding to DNA ends possessing pre-melted ssDNA tails of increasing length suggest that RecBCD interacts with ssDNA as long as 17-18 nucleotides and can melt at least 10-11 bp upon binding a blunt DNA end. Cryo-EM structures of RecBCD alone and in complex with a blunt-ended dsDNA show significant conformational heterogeneities associated with the RecB nuclease domain (RecB Nuc ) and the RecD subunit. In the absence of DNA, 56% of RecBCD molecules show no density for the RecB nuclease domain, RecB Nuc , and all RecBCD molecules show only partial density for RecD. DNA binding reduces these conformational heterogeneities, with 63% of the molecules showing density for both RecD and RecB Nuc . This suggests that the RecB Nuc domain is dynamic and influenced by DNA binding. The major RecBCD-DNA structural class in which RecB Nuc is docked onto RecC shows melting of at least 11 bp from a blunt DNA end, much larger than previously observed. A second structural class in which RecB Nuc is not docked shows only four bp melted suggesting that RecBCD complexes transition between states with different extents of DNA melting and that the extent of melting regulates initiation of helicase activity.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Biophysics, Washington University School of Medicine, 660 S. Euclid Avenue, Box 8231, Saint Louis, MO 63110, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
RecBCD enzyme subunit RecBA [auth B]1,180Escherichia coli K-12Mutation(s): 0
Gene Names: recBiorrorAb2820JW2788
EC: 3.1.11.5 (PDB Primary Data), 5.6.2.4 (UniProt)
UniProt
Find proteins for P08394 (Escherichia coli (strain K12))
Explore P08394
Go to UniProtKB:  P08394
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP08394
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
RecBCD enzyme subunit RecCB [auth C]1,122Escherichia coli K-12Mutation(s): 0
Gene Names: recCb2822JW2790
EC: 3.1.11.5
UniProt
Find proteins for P07648 (Escherichia coli (strain K12))
Explore P07648
Go to UniProtKB:  P07648
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07648
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
RecBCD enzyme subunit RecDC [auth D]608Escherichia coli K-12Mutation(s): 0
Gene Names: recDhopEb2819JW2787
EC: 3.1.11.5 (PDB Primary Data), 5.6.2.3 (UniProt)
UniProt
Find proteins for P04993 (Escherichia coli (strain K12))
Explore P04993
Go to UniProtKB:  P04993
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04993
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.30 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM045948
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35 GM136632

Revision History  (Full details and data files)

  • Version 1.0: 2021-07-28
    Type: Initial release
  • Version 1.1: 2021-08-11
    Changes: Database references
  • Version 1.2: 2024-05-29
    Changes: Data collection
