7K09 | pdb_00007k09

Puromycin N-acetyltransferase in complex with acetyl-CoA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.31 Å
  • R-Value Free:
    0.252 (Depositor), 0.268 (DCC)
  • R-Value Work:
    0.236 (Depositor), 0.251 (DCC)
  • R-Value Observed:
    0.237 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7K09

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Structure-guided selection of puromycin N-acetyltransferase mutants with enhanced selection stringency for deriving mammalian cell lines expressing recombinant proteins.

Caputo, A.T.Eder, O.M.Bereznakova, H.Pothuis, H.Ardevol, A.Newman, J.Nuttall, S.Peat, T.S.Adams, T.E.

(2021) Sci Rep 11: 5247-5247

  • DOI: https://doi.org/10.1038/s41598-021-84551-9
  • Primary Citation Related Structures:
    7K09, 7K0A

  • PubMed Abstract:

    Puromycin and the Streptomyces alboniger-derived puromycin N-acetyltransferase (PAC) enzyme form a commonly used system for selecting stably transfected cultured cells. The crystal structure of PAC has been solved using X-ray crystallography, revealing it to be a member of the GCN5-related N-acetyltransferase (GNAT) family of acetyltransferases. Based on structures in complex with acetyl-CoA or the reaction products CoA and acetylated puromycin, four classes of mutations in and around the catalytic site were designed and tested for activity. Single-residue mutations were identified that displayed a range of enzymatic activities, from complete ablation to enhanced activity relative to wild-type (WT) PAC. Cell pools of stably transfected HEK293 cells derived using two PAC mutants with attenuated activity, Y30F and A142D, were found to secrete up to three-fold higher levels of a soluble, recombinant target protein than corresponding pools derived with the WT enzyme. A third mutant, Y171F, appeared to stabilise the intracellular turnover of PAC, resulting in an apparent loss of selection stringency. Our results indicate that the structure-guided manipulation of PAC function can be utilised to enhance selection stringency for the derivation of mammalian cell lines secreting elevated levels of recombinant proteins.


  • Organizational Affiliation
    • Biomedical Manufacturing, Commonwealth Scientific and Industrial Research Organisation, 343 Royal Parade, Parkville, Victoria, 3052, Australia. alex.caputo@csiro.au.

Macromolecule Content

  • Total Structure Weight: 140.35 kDa
  • Atom Count: 9,159
  • Modeled Residue Count: 1,164
  • Deposited Residue Count: 1,248
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Puromycin N-acetyltransferase
A, B, C, D, E
A, B, C, D, E, F
208Streptomyces albonigerMutation(s): 0
Gene Names: pac
EC: 2.3
UniProt
Find proteins for P13249 (Streptomyces alboniger)
Explore P13249
Go to UniProtKB:  P13249
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13249
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.31 Å
  • R-Value Free:  0.252 (Depositor), 0.268 (DCC)
  • R-Value Work:  0.236 (Depositor), 0.251 (DCC)
  • R-Value Observed: 0.237 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 149.074α = 90
b = 73.63β = 90
c = 106.242γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
Aimlessdata scaling
MR-Rosettaphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-03-17
    Type: Initial release
  • Version 1.1: 2023-10-18
    Changes: Data collection, Database references, Refinement description
